符合ISO18752-DC标准;
4层或6层交错缠绕的高强度钢丝;
丁腈胶内胶层适用于可生物降解的液压油;
在业内领先的一百万次脉冲循环条件下测试;
温度范围-40°F~250°F(-40℃~121℃);
窄布纹黑色免剥外胶(耐天候三年以上)。
|
DN |
Inches |
I .D (mm) |
O.D(mm) |
Max.W.P |
Min. B.P |
Min. B.R |
|
|
Min |
Max |
Max |
(Mpa) |
(Mpa) |
(mm) |
||
|
6 |
1/4-4S |
6.2 |
7.0 |
18.7 |
70 |
280 |
120 |
|
10 |
3/8-4S |
9.3 |
10.1 |
22.2 |
56 |
224 |
150 |
|
13 |
1/2-4S |
12.8 |
13.5 |
25.0 |
42 |
168 |
190 |
|
16 |
5/8-4S |
15.9 |
16.6 |
28.4 |
42 |
168 |
200 |
|
19 |
3/4-4S |
18.8 |
19.6 |
32.3 |
42 |
168 |
224 |
|
25 |
1"-4S |
25.0 |
25.8 |
39.3 |
42 |
168 |
272 |
|
32 |
1-1/4-4S |
31.6 |
32.6 |
46.0 |
35 |
140 |
370 |
|
32 |
1-1/4-6S |
31.6 |
32.6 |
50.8 |
42 |
168 |
420 |
|
38 |
1-1/2-6S |
37.7 |
38.8 |
57.3 |
42 |
168 |
500 |
|
51 |
2"-6S |
51.6 |
51.8 |
71.5 |
42 |
168 |
650 |
