Application: for the delivery of water, hydraulic oil and various chemical media
Inner tube: PTFE
Outer layer: abrasion resistant synthetic rubber
Reinforcement: 4-8 layer of high tensile spiral steel wire
Temperature range:-55℃~+200℃
| 规格 Specifications | |||||
|
软管内径 mm |
软管外径 mm |
最大工作压力 MAX Rec.WP（PSI） |
最小爆破压力 Mpa |
Weight 重量 (KG/M) |
|
| 5/32 | 12 | 300 | 780 | 0.40 | |
| 3/16 | 13 | 250 | 625 | 0.41 | |
| 3/8 | 21.6 | 160 | 400 | 0.94 | |
| 1/2 | 27 | 200 | 500 | 1.85 | |
| 3/4 | 33.7 | 112 | 280 |
1.76 |
|
