采用高强度合金钢锻造而成，严格的热处理确保接头有匀均一致的金相组织和承压能力，所使用材料完全符合美国ASTM和AISI标准，产品技术指标完全符合API Spec 6A标准，产品密封可靠、装卸快捷、通用互换性好。产品可用管线螺纹、油管螺纹、对焊式或压密封端部连接。

602型装有弹性丁腈橡胶密封环,用于密封并保护由壬钢对钢的配合。

推荐用于歧管管线连接,车载及泥浆输送场合,可用于无压密封由壬。采用对焊Sch.80/160。

采用高强度合金钢锻造而成，严格的热处理确保接头有匀均一致的金相组织和承压能力，所使用材料完全符合美国ASTM和AISI标准，产品技术指标完全符合API Spec 6A标准，产品密封可靠、装卸快捷、通用互换性好。产品可用管线螺纹、油管螺纹、对焊式或压密封端部连接。

1003型由壬具有一个球形座,可以提供偏离中心71/2度的偏斜或角度调整，总的偏斜能力是15度。除钢对钢的配合外,丁腈橡胶O-型环保证了在任何偏斜位置连接的气密性.可提供管线螺纹或对焊连接.

推荐用于不能对正时的高压管线连接,可应用于空气、水、油、泥浆或气体使用场合。

采用高强度合金钢锻造而成，严格的热处理确保接头有匀均一致的金相组织和承压能力，所使用材料完全符合美国ASTM和AISI标准，产品技术指标完全符合API Spec 6A标准，产品密封可靠、装卸快捷、通用互换性好。产品可用管线螺纹、油管螺纹、对焊式或压密封端部连接。

FIG1004型由壬5”6”两种规格为橡胶O型密封圈密封。对于同心性要求高，反之会产生密封事故。为了克服这种状况，最新引入了两个新的大小的对接焊缝的由

壬,利用唇型弹性体密封安装。这种新型由壬被称为“FIG1004型”。可以标准服务或酸气(H2s)。

Fig.1004联盟的目的是工作压力以下。

标准服务:10000 psi cwp

酸气服务:7500 psi cwp

1502型由壬是使用最广泛的，可以管线螺纹和焊接连接，分为标准和酸气服务，最新引进Fig5”6”型，配有可更换的弹性丁腈橡胶密封环，坚固壁厚设计用于高压系统。

推荐用于注水泥、压裂、酸化、测试及堵塞和压井管线，也可用于无压密封连接，采用对焊Sch XXH。

2202型由壬只应用对焊服务，配有一个可更换的弹性丁腈橡胶密封环组合在不锈钢衬管中，在超压力应用场合提供完全的挤压保护。可拆开的螺母/扇形环/持环设计简化了螺母从管道上的拆卸。

部件号 Part Number	规格（英寸） Size (in.)	外径A （英寸） OD A (in.)	Bore B	圆环C （英寸） Circle C (in.)	厚度（英寸） Thickness (in.)	螺栓孔数量 Number Bolt Holes	螺栓孔直径 Diameter Bolt Holes (in.)	单个重量（公斤） Weight Each (KG)
SSPF3160075	3/4	3 7/8	1.100	2 3/4	1/2	4	5/8	0.62
SSPF3160100	1	4 1/4	1.360	3 1/8	1/2	4	5/8	0.75
SSPF3160125	1 1/4	4 5/8	1.700	3 1/2	1/2	4	5/8	0.91
SSPF3160150	1 1/2	5	1.950	3 7/8	1/2	4	5/8	1.02
SSPF3160200	2	6	2.440	4 3/4	1/2	4	3/4	1.39
SSPF3160250	2 1/2	7	2.940	5 1/2	1/2	4	3/4	1.98
SSPF3160300	3	7 1/2	3.570	6	1/2	4	3/4	2.14
SSPF3160400	4	9	4.570	7 1/2	1/2	8	3/4	2.88
SSPF3160500	5	10	5.660	8 1/2	1/2	8	7/8	3.21
SSPF3160600	6	11	6.720	9 1/2	1/2	8	7/8	3.47
SSPF3160800	8	13 1/2	8.720	11 3/4	1/2	8	7/8	5.19
SSPF3161000	10	16	10.880	14 1/4	1/2	12	1	6.06
SSPF3161200	12	19	12.880	17	1/2	12	1	9.53
SSPF3161400	14	21	14.140	18 3/4	1/2	12	1 1/8	12.62
SSPF3161600	16	23 1/2	16.160	21 1/4	1/2	16	1 1/8	13.61

2202型由壬只应用对焊服务，配有一个可更换的弹性丁腈橡胶密封环组合在不锈钢衬管中，在超压力应用场合提供完全的挤压保护。可拆开的螺母/扇形环/持环设计简化了螺母从管道上的拆卸。

采用高强度合金钢锻造而成，严格的热处理确保接头有匀均一致的金相组织和承压能力，所使用材料完全符合美国ASTM和AISI标准，产品技术指标完全符合API

Spec 6A标准，产品密封可靠、装卸快捷、通用互换性好。产品可用管线螺纹、油管螺纹、对焊式或压密封端部连接。

1002型装有弹性丁腈橡胶密封环

推荐用于注水泥、压裂、酸化、测试及堵塞和压井管线场合。设计用于高压系统，包括车载系统。也可用作无压密封由壬。采用以焊Sch.160或XXH。

采用高强度合金钢锻造而成，严格的热处理确保接头有匀均一致的金相组织和承压能力，所使用材料完全符合美国ASTM和AISI标准，产品技术指标完全符合API Spec 6A标准，产品密封可靠、装卸快捷、通用互换性好。产品可用管线螺纹、油管螺纹、对焊式或压密封端部连接。吸入端由壬材质为碳钢。螺母和O型圈是常规尺寸。尺寸有4”和5”。连接是螺纹和承插焊接。由壬压力级别：500 PSI wp。

采用高强度合金钢锻造而成，严格的热处理确保接头有匀均一致的金相组织和承压能力，所使用材料完全符合美国ASTM和AISI标准，产品技术指标完全符合API Spec 6A标准，产品密封可靠、装卸快捷、通用互换性好。产品可用管线螺纹、油管螺纹、对焊式或压密封端部连接。

207型由壬封头帽上装有厂腈橡胶O-型环以进行有效的封闭,螺纹接头可与200和206型螺纹接头进行互换,可用型号采用对焊Sch.40。

推荐用于空气、水、油或汽应用场合密封歧管连接和保护管线接头螺纹。

采用高强度合金钢锻造而成，严格的热处理确保接头有匀均一致的金相组织和承压能力，所使用材料完全符合美国ASTM和AISI标准，产品技术指标完全符合API Spec 6A标准，产品密封可靠、装卸快捷、通用互换性好。产品可用管线螺纹、油管螺纹、对焊式或压密封端部连接。

211型由壬接头的绝缘设计消除了连接中金属对金属的接触，同时复式抗磨损精密制造的合成橡胶提供了有效的密封。可更换环形密封组件以延长由壬的使用寿命。

推荐用于存在电解腐蚀问题的应用场合，或需要静电隔离管线部分的场合。

采用高强度合金钢锻造而成，严格的热处理确保接头有匀均一致的金相组织和承压能力，所使用材料完全符合美国ASTM和AISI标准，产品技术指标完全符合API Spec 6A标准，产品密封可靠、装卸快捷、通用互换性好。产品可用管线螺纹、油管螺纹、对焊式或压密封端部连接。

400型采用壁厚和坚固的设计,具有环形和锥形金属密封,以便容易进行对中和可靠的密封.适用于空气、水、石油、天然气和泥浆服务4000 psi NSCWP。

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREAD E	公称内径 DN	标号DASH	A	C	S2
19611-04-04RW	--	G1/4”X19	6	04	28	16	17
19611-06-06RW	--	G3/8”X19	10	06	29.5	18	19
19611-08-08RW	19612-08-08RW	G1/2”X14	12	08	34.5	20	22
19611-12-12RW	19612-12-12RW	G3/4”X14	20	12	38	22	30
19611-16-16RW	19612-16-16RW	G1”X11	25	16	44.2	24	36

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREAD E	公称内径 DN	标号DASH	A	C	S1	S2
29611-04-04RW	--	G1/4”X19	6	04	20.5	8	19	19
29611-04-05RW	--	G1/4”X19	8	05	20.5	8	19	19
29611-06-04RW	--	G3/8”X19	6	04	23.5	9	22	22
29611-06-06RW	--	G3/8”X19	10	06	23	9	22	22
29611-08-06RW	--	G1/2”X14	10	06	24.5	12	27	27
29611-08-08RW	29612-08-08RW	G1/2”X14	12	08	25.5	12	27	27
29611-10-10RW	29612-10-10RW	G5/8”X14	16	10	29.5	11.5	30	30
29611-12-10RW	29612-12-10RW	G3/4”X14	16	10	29.5	13.5	32	32
29611-12-12RW	29612-12-12RW	G3/4”X14	20	12	28.5	13.5	32	32
29611-16-16RW	29612-16-16RW	G1”X14	25	16	33.2	16	41	41
29611-20-20WRW	29612-20-20WRW	G1.1/4”X11	32	20	39.2	18.5	50	50
29611-24-24WRW	29612-24-24WRW	G1.1/2”X11	40	24	41.5	19	55	55
29611-32-32WRW	29612-32-32WRW	G2”X11	50	32	49	23	70	70

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREAD E	公称内径 DN	标号DASH	A	C	H	S1	S2
29641-04-04RW	--	G1/4”X19	6	04	44.9	8	21.3	19	19
29641-06-06RW	--	G3/8”X19	10	06	50.2	9	25	22	22
29641-08-08RW	29642-08-08RW	G1/2”X14	12	08	63.9	12	27.5	27	27
29641-10-10RW	29642-10-10RW	G5/8”X14	16	10	76.6	11.5	31.3	30	30
29641-12-12RW	29642-12-12RW	G3/4”X14	20	12	79.9	13.5	34.1	32	32
29641-16-16RW	29642-16-16RW	G1”X14	25	16	93.2	16	36.8	41	41
29641-20-20WRW	29642-20-20WRW	G1.1/4”X11	32	20	107	18.5	45.1	50	50
29641-24-24WRW	29642-24-24WRW	G1.1/2”X11	40	24	122.8	19	50.1	55	55
29641-32-32WRW	29642-32-32WRW	G2”X11	50	32	149.9	23	60.1	70	70

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREAD E	公称内径 DN	标号DASH	A	C	H	S1	S2
29691-04-04RW	--	G1/4”X19	6	04	31.5	8	38	19	19
29691-04-05RW	--	G1/4”X19	8	05	34.5	8	41	19	19
29691-06-06RW	--	G3/8”X19	10	06	36.3	9	46.3	22	22
29691-08-08RW	29692-08-08RW	G1/2”X14	12	08	42.5	12	53	27	27
29691-10-10RW	29692-10-10RW	G5/8”X14	16	10	57	11.5	61	30	30
29691-12-12RW	29692-12-12RW	G3/4”X14	20	12	63.2	13.5	67.5	32	32
29691-16-16RW	29692-16-16RW	G1”X14	25	16	78.9	16	77.5	41	41
29691-20-20WRW	29692-20-20WRW	G1.1/4”X11	32	20	92.7	18.5	94.5	50	50
29691-24-24WRW	29692-24-24WRW	G1.1/2”X11	40	24	111.4	19	109.5	55	55
29691-32-32WRW	29692-32-32WRW	G2”X11	50	32	138.6	23	133.8	70	70

代号	螺纹E	软管		尺寸
代号	螺纹E	公称内径	标号	A	C	H	S2
22141-02-04	G1/8”X28	6	04	43.7	2	21.6	14
22141-04-03	G1/4”X19	5	03	41.3	4	20.4	19
22141-04-04	G1/4”X19	6	04	43.7	4	21.6	19
22141-06-05	G3/8”X19	8	05	46.2	5	22.9	22
22141-06-06	G3/8”X19	10	06	48.1	5	23.9	22
22141-06-08	G3/8”X19	12	08	60.4	5	25.4	22
22141-08-04T	G1/2”X14	6	04	43.9	6	23.8	27
22141-08-06T	G1/2”X14	10	06	42.5	6	18.2	27
22141-08-08	G1/2”X14	12	08	61.8	6	26.8	27
22141-08-10	G1/2”X14	16	10	73	6	29	27
22141-10-10	G5/8”X14	16	10	73.7	8	28.9	30
22141-10-12	G5/8”X14	20	12	79.8	8	32.5	30
22141-12-08T	G3/4”X14	12	08	63.2	9.5	28.3	32
22141-12-10	G3/4”X14	16	10	70.4	9.5	29.6	32
22141-12-12	G3/4”X14	20	12	80.6	9.5	33.2	32
22141-16-12	G1”X11	20	12	81.6	11	33.5	41
22141-16-14	G1”X11	22	14	83.3	11	33	41
22141-16-16	G1”X11	25	16	89.2	11	35	41
22141-20-16T	G1.1/4”X11	25	16	91.4	9.1	37.1	50
22141-20-20W	G1.1/4”X11	32	20	102.9	10	41.2	50
22141-24-24W	G1.1/2”X11	40	24	119.8	11.5	49	55
22141-32-32W	G2”X11	50	32	137.4	15	53	70
注：1.上诉代号用于编制软管。 2.如需用于缠绕软管代码号改为22142-xx-xx。 NOTE : 1.FOR USE WITH BRAIDED HOSES 2.IF USE WITH SPIRAL HOSES ,HOSE FITTINGS SERIES NUMBER IS 22142-XX-XX.

代号 PART NO.		法兰型号	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	FLANGE SIZE	公称内径 DN	标号DASH	A	C	D	H	L
87341-08-08RW	87342-08-08RW	1/2”	12	08	59.7	30.2	24	23.3	6.73
87341-12-08RW	87342-12-08RW	3/4”	12	08	60.4	38.1	31.7	24	6.73
87341-12-10RW	87342-12-10RW	3/4”	16	10	70.6	38.1	31.7	25.3	6.73
87341-12-12RW	87342-12-12RW	3/4”	20	12	73.9	38.1	31.7	28.1	6.73
87341-12-16RW	87342-12-16RW	3/4”	25	16	86.1	38.1	31.7	29.7	6.73
87341-16-12RW	87342-16-12RW	1”	20	12	73.9	44.4	38	28.1	8
87341-16-16RW	87342-16-16RW	1”	25	16	86.1	44.4	38	29.7	8
87341-16-20RW	87342-16-20RW	1”	32	20	95.7	44.4	38	33.8	8
87341-20-16RW	87342-20-16RW	1.1/4”	25	16	86.1	50.8	43	29.7	8
87341-20-20RW	87342-20-20RW	1.1/4”	32	20	95.7	50.8	43	33.8	8
87341-24-20RW	87342-24-20RW	1.1/2”	32	20	97.1	60.3	50	35.2	8
87341-24-24RW	87342-24-24RW	1.1/2”	40	24	111.8	60.3	50	39.1	8
87341-32-24RW	87342-32-24RW	2”	40	24	111.8	71.4	62	39.1	9.53
87341-32-32RW	87342-32-32RW	2”	50	32	136.1	71.4	62	46.3	9.53

代号	法兰型号	软管		尺寸
代号	法兰型号	公称内径	标号	A	C	D	L
97312-08-08	1/2”	12	08	45.5	30.2	24	6.73
97312-12-08	3/4”	12	08	47.5	38.1	31.7	6.73
97312-12-10	3/4”	16	10	49	38.1	31.7	6.73
97312-12-12	3/4”	20	12	48.5	38.1	31.7	6.73
97312-12-16	3/4”	25	16	49	38.1	31.7	6.73
97312-16-12	1”	20	12	51	44.4	38	8
97312-16-16	1”	25	16	48	44.4	38	8
97312-16-20	1”	32	20	53	44.4	38	8
97312-20-16	1.1/4”	25	16	57	50.8	43	8
97312-20-20	1.1/4”	32	20	56	50.8	43	8
97312-24-20	1.1/2”	32	20	68	60.3	50	8
97312-24-24	1.1/2”	40	24	74	60.3	50	8
97312-32-24	2”	40	24	70	71.4	62	9.53
97312-32-32	2”	50	32	70	71.4	62	9.53
97312-40-40	2.1/2”	64	40	76	84.1	74	9.53
注：1.上诉代号用于编制软管。 2.如需用于缠绕软管代码号改为87312-xx-xx。 NOTE : 1.FOR USE WITH BRAIDED HOSES 2.IF USE WITH SPIRAL HOSES ,HOSE FITTINGS SERIES NUMBER IS 87312-XX-XX.

代号 PART NO.		法兰型号	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	FLANGE SIZE	公称内径 DN	标号DASH	A	C	D	H	L
87691-08-08RW	87692-08-08RW	1/2”	12	08	42.5	30.2	24	48	6.73
87691-12-08RW	87692-12-08RW	3/4”	12	08	42.5	38.1	31.7	52	6.73
87691-12-10RW	87692-12-10RW	3/4”	16	10	57	38.1	31.7	56.5	6.73
87691-12-12RW	87692-12-12RW	3/4”	20	12	63.2	38.1	31.7	63	6.73
87691-12-16RW	87692-12-16RW	3/4”	25	16	78.9	38.1	31.7	71.5	6.73
87691-16-12RW	87692-16-12RW	1”	20	12	63.2	44.4	38	66	8
87691-16-16RW	87692-16-16RW	1”	25	16	78.9	44.4	38	74.5	8
87691-16-20RW	87692-16-20RW	1”	32	20	92.7	44.4	38	85.5	8
87691-20-16RW	87692-20-16RW	1.1/4”	25	16	78.9	50.8	43	78.5	8
87691-20-20RW	87692-20-20RW	1.1/4”	32	20	92.7	50.8	43	89.5	8
87691-24-20RW	87692-24-20RW	1.1/2”	32	20	92.7	60.3	50	94.5	8
87691-24-24RW	87692-24-24RW	1.1/2”	40	24	111.4	60.3	50	108	8
87691-32-24RW	87692-32-24RW	2”	40	24	111.4	71.4	62	116	9.53
87691-32-32RW	87692-32-32RW	2”	50	32	138.6	71.4	62	136.3	9.53

代号 PART NO.		法兰型号	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	FLANGE SIZE	公称内径 DN	标号DASH	A	C	D	H	L
87391-08-08RW	87392-08-08RW	1/2”	12	08	42.5	30.2	24	47	6.73
87391-12-08RW	87392-12-08RW	3/4”	12	08	42.5	38.1	31.7	48	6.73
87391-12-10RW	87392-12-10RW	3/4”	16	10	57	38.1	31.7	52.5	6.73
87391-12-12RW	87392-12-12RW	3/4”	20	12	63.2	38.1	31.7	59	6.73
87391-12-16RW	87392-12-16RW	3/4”	25	16	78.9	38.1	31.7	67.5	6.73
87391-16-12RW	87392-16-12RW	1”	20	12	63.2	44.4	38	59	8
87391-16-16RW	87392-16-16RW	1”	25	16	78.9	44.4	38	67.5	8
87391-16-20RW	87392-16-20RW	1”	32	20	92.7	44.4	38	78.5	8
87391-20-16RW	87392-20-16RW	1.1/4”	25	16	78.9	50.8	43	67.5	8
87391-20-20RW	87392-20-20RW	1.1/4”	32	20	92.7	50.8	43	78.5	8
87391-24-20RW	87392-24-20RW	1.1/2”	32	20	92.7	60.3	50	80.5	8
87391-24-24RW	87392-24-24RW	1.1/2”	40	24	111.4	60.3	50	94	8
87391-32-24RW	87392-32-24RW	2”	40	24	111.4	71.4	62	94	9.53
87391-32-32RW	87392-32-32RW	2”	50	32	138.6	71.4	62	114.3	9.53

代号	法兰型号	软管		尺寸
代号	法兰型号	公称内径	标号	A	C	D	H	L
87342-08-08	1/2”	12	08	56.5	30.2	24	23.5	6.73
87342-12-08	3/4”	12	08	58.9	38.1	31.7	24	6.73
87342-12-10	3/4”	16	10	69.9	38.1	31.7	25.3	6.73
87342-12-12	3/4”	20	12	73.5	38.1	31.7	29.5	6.73
87342-16-12	1”	20	12	76.3	44.4	38	28.9	8
87342-16-16	1”	25	16	83	44.4	38	31	8
87342-16-20	1”	32	20	94.5	44.4	38	33.8	8
87342-20-16	1.1/4”	25	16	82	50.8	43	30.5	8
87342-20-20	1.1/4”	32	20	95	50.8	43	36	8
87342-24-20	1.1/2”	32	20	95.9	60.3	50	35.2	8
87342-24-24	1.1/2”	40	24	108	60.3	50	42	8
87342-32-24	2”	40	24	109.9	71.4	62	39.1	9.53
87342-32-32	2”	50	32	129.3	71.4	62	43	9.53
注：1.上诉代号用于编制软管。 2.如需用于缠绕软管代码号改为87342-xx-xx。 NOTE : 1.FOR USE WITH BRAIDED HOSES 2.IF USE WITH SPIRAL HOSES ,HOSE FITTINGS SERIES NUMBER IS 87342-XX-XX.

代号	法兰型号	软管		尺寸
代号	法兰型号	公称内径	标号	A	C	D	H	L
87642-08-08	1/2”	12	08	57.5	31.7	24	25	7.75
87642-08-12	1/2”	20	12	77	31.7	24	29.6	7.75
87642-12-10	3/4”	16	10	72.5	41.3	32	28.2	8.76
87642-12-12	3/4”	20	12	75.5	41.3	32	32	8.76
87642-16-16	1”	25	16	86	47.6	38	34	9.53
87642-20-20	1.1/4”	32	20	100	54	44	40	10.29
87642-24-20	1.1/2”	32	20	105.8	63.5	51	45.1	12.57
87642-24-24	1.1/2”	40	24	112	63.5	51	46	12.57
87642-32-24	2”	40	24	125.4	79.4	67	54.7	12.57
87642-32-32	2”	50	32	143	79.4	67	49	12.57
注：1.上诉代号用于编制软管。 2.如需用于缠绕软管代码号改为87642-xx-xx。 NOTE : 1.FOR USE WITH BRAIDED HOSES 2.IF USE WITH SPIRAL HOSES ,HOSE FITTINGS SERIES NUMBER IS 87642-XX-XX.

代号 PART NO.		法兰型号	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	FLANGE SIZE	公称内径 DN	标号DASH	A	C	D	L
87611-08-08RW	87612-08-08RW	1/2”	12	08	48.5	31.7	24	7.75
87611-12-08RW	87612-12-08RW	3/4”	12	08	51.5	41.3	32	8.76
87611-12-10RW	87612-12-10RW	3/4”	16	10	52	41.3	32	8.76
87611-12-12RW	87612-12-12RW	3/4”	20	12	51	41.3	32	8.76
87611-12-16RW	87612-12-16RW	3/4”	25	16	54.2	41.3	32	8.76
87611-16-12RW	87612-16-12RW	1”	20	12	56	47.6	38	9.53
87611-16-16RW	87612-16-16RW	1”	25	16	59.2	47.6	38	9.53
87611-16-20RW	87612-16-20RW	1”	32	20	59.2	47.6	38	9.53
87611-20-16RW	87612-20-16RW	1.1/4”	25	16	67.2	54	44	10.29
87611-20-20RW	87612-20-20RW	1.1/4”	32	20	67.2	54	44	10.29
87611-24-20RW	87612-24-20RW	1.1/2”	32	20	76.2	63.5	51	12.57
87611-24-24RW	87612-24-24RW	1.1/2”	40	24	77	63.5	51	12.57
87611-32-24RW	87612-32-24RW	2”	40	24	88	79.4	67	12.57
87611-32-32RW	87612-32-32RW	2”	50	32	91.5	79.4	67	12.57

代号 PART NO.		法兰型号	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	FLANGE SIZE	公称内径 DN	标号DASH	A	C	D	L
87311-08-08RW	87311-08-08RW	1/2”	12	08	47.5	30.2	24	6.73
87311-12-08RW	87311-12-08RW	3/4”	12	08	48.5	38.1	31.7	6.73
87311-12-10RW	87311-12-10RW	3/4”	16	10	49	38.1	31.7	6.73
87311-12-12RW	87311-12-12RW	3/4”	20	12	48	38.1	31.7	6.73
87311-12-16RW	87311-12-16RW	3/4”	25	16	51.2	38.1	31.7	6.73
87311-16-12RW	87311-16-12RW	1”	20	12	51	44.4	38	8
87311-16-16RW	87311-16-16RW	1”	25	16	54.2	44.4	38	8
87311-16-20RW	87311-16-20RW	1”	32	20	54.2	44.4	38	8
87311-20-16RW	87311-20-16RW	1.1/4”	25	16	59.2	50.8	43	8
87311-20-20RW	87311-20-20RW	1.1/4”	32	20	59.2	50.8	43	8
87311-24-20RW	87311-24-20RW	1.1/2”	32	20	69.2	60.3	50	8
87311-24-24RW	87311-24-24RW	1.1/2”	40	24	70	60.3	50	8
87311-32-24RW	87311-32-24RW	2”	40	24	72	71.4	62	9.53
87311-32-32RW	87311-32-32RW	2”	50	32	75.5	71.4	62	9.53

代号	法兰型号	软管		尺寸
代号	法兰型号	公称内径	标号	A	C	D	H	L
87692-08-08	1/2”	12	08	42.5	31.7	24	25	7.75
87692-12-10	3/4”	16	10	56	41.3	32	56.5	8.76
87692-12-12	3/4”	20	12	50.5	41.3	32	65.5	8.76
87692-16-12	1”	20	12	65.5	47.6	38	69	9.53
87692-16-16	1”	25	16	66	47.6	38	78	9.53
87692-16-20	1”	32	20	91.5	47.6	38	85.5	9.53
87692-20-16	1.1/4”	25	16	76.7	54	44	78.5	10.29
87692-20-20	1.1/4”	32	20	75	54	44	92	10.29
87692-24-20	1.1/2”	32	20	91.5	63.5	51	94.5	12.57
87692-24-24	1.1/2”	40	24	89	63.5	51	107	12.57
87692-32-24	2”	40	24	109.4	79.4	67	116	12.57
87692-32-32	2”	50	32	115.5	79.4	67	138.5	12.57
注：1.上诉代号用于编制软管。 2.如需用于缠绕软管代码号改为87692-xx-xx。 NOTE : 1.FOR USE WITH BRAIDED HOSES 2.IF USE WITH SPIRAL HOSES ,HOSE FITTINGS SERIES NUMBER IS 87692-XX-XX.

代号 PART NO.		法兰型号	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	FLANGE SIZE	公称内径 DN	标号DASH	A	C	D	H	L
87341-08-08RW	87342-08-08RW	1/2”	12	08	59.7	30.2	24	23.3	6.73
87341-12-08RW	87342-12-08RW	3/4”	12	08	60.4	38.1	31.7	24	6.73
87341-12-10RW	87342-12-10RW	3/4”	16	10	70.6	38.1	31.7	25.3	6.73
87341-12-12RW	87342-12-12RW	3/4”	20	12	73.9	38.1	31.7	28.1	6.73
87341-12-16RW	87342-12-16RW	3/4”	25	16	86.1	38.1	31.7	29.7	6.73
87341-16-12RW	87342-16-12RW	1”	20	12	73.9	44.4	38	28.1	8
87341-16-16RW	87342-16-16RW	1”	25	16	86.1	44.4	38	29.7	8
87341-16-20RW	87342-16-20RW	1”	32	20	95.7	44.4	38	33.8	8
87341-20-16RW	87342-20-16RW	1.1/4”	25	16	86.1	50.8	43	29.7	8
87341-20-20RW	87342-20-20RW	1.1/4”	32	20	95.7	50.8	43	33.8	8
87341-24-20RW	87342-24-20RW	1.1/2”	32	20	97.1	60.3	50	35.2	8
87341-24-24RW	87342-24-24RW	1.1/2”	40	24	111.8	60.3	50	39.1	8
87341-32-24RW	87342-32-24RW	2”	40	24	111.8	71.4	62	39.1	9.53
87341-32-32RW	87342-32-32RW	2”	50	32	136.1	71.4	62	46.3	9.53

代号	法兰型号	软管		尺寸
代号	法兰型号	公称内径	标号	A	C	D	L
97312-08-08	1/2”	12	08	45.5	30.2	24	6.73
97312-12-08	3/4”	12	08	47.5	38.1	31.7	6.73
97312-12-10	3/4”	16	10	49	38.1	31.7	6.73
97312-12-12	3/4”	20	12	48.5	38.1	31.7	6.73
97312-12-16	3/4”	25	16	49	38.1	31.7	6.73
97312-16-12	1”	20	12	51	44.4	38	8
97312-16-16	1”	25	16	48	44.4	38	8
97312-16-20	1”	32	20	53	44.4	38	8
97312-20-16	1.1/4”	25	16	57	50.8	43	8
97312-20-20	1.1/4”	32	20	56	50.8	43	8
97312-24-20	1.1/2”	32	20	68	60.3	50	8
97312-24-24	1.1/2”	40	24	74	60.3	50	8
97312-32-24	2”	40	24	70	71.4	62	9.53
97312-32-32	2”	50	32	70	71.4	62	9.53
97312-40-40	2.1/2”	64	40	76	84.1	74	9.53
注：1.上诉代号用于编制软管。 2.如需用于缠绕软管代码号改为87312-xx-xx。 NOTE : 1.FOR USE WITH BRAIDED HOSES 2.IF USE WITH SPIRAL HOSES ,HOSE FITTINGS SERIES NUMBER IS 87312-XX-XX.

代号 PART NO.		法兰型号	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	FLANGE SIZE	公称内径 DN	标号DASH	A	C	D	H	L
87691-08-08RW	87692-08-08RW	1/2”	12	08	42.5	30.2	24	48	6.73
87691-12-08RW	87692-12-08RW	3/4”	12	08	42.5	38.1	31.7	52	6.73
87691-12-10RW	87692-12-10RW	3/4”	16	10	57	38.1	31.7	56.5	6.73
87691-12-12RW	87692-12-12RW	3/4”	20	12	63.2	38.1	31.7	63	6.73
87691-12-16RW	87692-12-16RW	3/4”	25	16	78.9	38.1	31.7	71.5	6.73
87691-16-12RW	87692-16-12RW	1”	20	12	63.2	44.4	38	66	8
87691-16-16RW	87692-16-16RW	1”	25	16	78.9	44.4	38	74.5	8
87691-16-20RW	87692-16-20RW	1”	32	20	92.7	44.4	38	85.5	8
87691-20-16RW	87692-20-16RW	1.1/4”	25	16	78.9	50.8	43	78.5	8
87691-20-20RW	87692-20-20RW	1.1/4”	32	20	92.7	50.8	43	89.5	8
87691-24-20RW	87692-24-20RW	1.1/2”	32	20	92.7	60.3	50	94.5	8
87691-24-24RW	87692-24-24RW	1.1/2”	40	24	111.4	60.3	50	108	8
87691-32-24RW	87692-32-24RW	2”	40	24	111.4	71.4	62	116	9.53
87691-32-32RW	87692-32-32RW	2”	50	32	138.6	71.4	62	136.3	9.53

代号 PART NO.		法兰型号	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	FLANGE SIZE	公称内径 DN	标号DASH	A	C	D	H	L
87391-08-08RW	87392-08-08RW	1/2”	12	08	42.5	30.2	24	47	6.73
87391-12-08RW	87392-12-08RW	3/4”	12	08	42.5	38.1	31.7	48	6.73
87391-12-10RW	87392-12-10RW	3/4”	16	10	57	38.1	31.7	52.5	6.73
87391-12-12RW	87392-12-12RW	3/4”	20	12	63.2	38.1	31.7	59	6.73
87391-12-16RW	87392-12-16RW	3/4”	25	16	78.9	38.1	31.7	67.5	6.73
87391-16-12RW	87392-16-12RW	1”	20	12	63.2	44.4	38	59	8
87391-16-16RW	87392-16-16RW	1”	25	16	78.9	44.4	38	67.5	8
87391-16-20RW	87392-16-20RW	1”	32	20	92.7	44.4	38	78.5	8
87391-20-16RW	87392-20-16RW	1.1/4”	25	16	78.9	50.8	43	67.5	8
87391-20-20RW	87392-20-20RW	1.1/4”	32	20	92.7	50.8	43	78.5	8
87391-24-20RW	87392-24-20RW	1.1/2”	32	20	92.7	60.3	50	80.5	8
87391-24-24RW	87392-24-24RW	1.1/2”	40	24	111.4	60.3	50	94	8
87391-32-24RW	87392-32-24RW	2”	40	24	111.4	71.4	62	94	9.53
87391-32-32RW	87392-32-32RW	2”	50	32	138.6	71.4	62	114.3	9.53

代号	法兰型号	软管		尺寸
代号	法兰型号	公称内径	标号	A	C	D	H	L
87342-08-08	1/2”	12	08	56.5	30.2	24	23.5	6.73
87342-12-08	3/4”	12	08	58.9	38.1	31.7	24	6.73
87342-12-10	3/4”	16	10	69.9	38.1	31.7	25.3	6.73
87342-12-12	3/4”	20	12	73.5	38.1	31.7	29.5	6.73
87342-16-12	1”	20	12	76.3	44.4	38	28.9	8
87342-16-16	1”	25	16	83	44.4	38	31	8
87342-16-20	1”	32	20	94.5	44.4	38	33.8	8
87342-20-16	1.1/4”	25	16	82	50.8	43	30.5	8
87342-20-20	1.1/4”	32	20	95	50.8	43	36	8
87342-24-20	1.1/2”	32	20	95.9	60.3	50	35.2	8
87342-24-24	1.1/2”	40	24	108	60.3	50	42	8
87342-32-24	2”	40	24	109.9	71.4	62	39.1	9.53
87342-32-32	2”	50	32	129.3	71.4	62	43	9.53
注：1.上诉代号用于编制软管。 2.如需用于缠绕软管代码号改为87342-xx-xx。 NOTE : 1.FOR USE WITH BRAIDED HOSES 2.IF USE WITH SPIRAL HOSES ,HOSE FITTINGS SERIES NUMBER IS 87342-XX-XX.

代号	螺纹E	软管		管子外径	O形圈	尺寸
代号	螺纹E	公称内径	标号	管子外径	O形圈	A	C	H	S2
20591-14-04	M16X1.5	6	04	6	O04.5X1.5	27.5	1.5	45.4	19
20591-16-04	M16X1.5	6	04	8	O06.5X1.5	27.5	1.5	45.5	22
20591-16-05	M16X1.5	8	05	8	O06.5X1.5	31	1.5	50	22
20591-18-05T	M18X1.5	8	05	10	O08.0X1.5	31	1.5	43.5	22
20591-18-06	M18X1.5	10	06	10	O08.0X1.5	33	2	53	24
20591-20-06T	M20X1.5	10	06	12	O10.0X1.5	33	2.5	46.5	24
20591-20-08	M20X1.5	12	08	12	O10.0X1.5	42.5	2.5	61.5	27
20591-22-06T	M22X1.5	10	06	14	O11.0X2.0	33	3	47	27
20591-22-08	M22X1.5	12	08	14	O11.0X2.0	42.5	2.5	62.5	27
20591-24-08T	M24X1.5	12	08	16	O13.0X2.0	42.5	3	55	30
20591-24-10	M24X1.5	16	10	16	O13.0X2.0	48.5	2.5	68	30
20591-30-10T	M30X2	16	10	20	O16.3X2.4	48.5	2.5	60.5	36
20591-30-12	M30X2	20	12	20	O16.3X2.4	50.5	3	78.5	36
20591-36-12T	M36X2	20	12	25	O20.3X2.4	50.5	3.2	72	46
20591-36-14T	M36X2	22	14	25	O20.3X2.4	57.5	3.2	74	46
20591-42-16T	M42X2	25	16	30	O25.3X2.4	66	3.9	83	50
20591-52-20T	M52X2	32	20	38	O33.3X2.4	75	4.5	95.5	60
20591-52-24T	M52X2	40	24	38	O33.3X2.4	93	4.5	107.5	60
注：1.上诉代号用于编制软管。 2.如需用于缠绕软管代码号改为20592-xx-xx。 NOTE : 1.FOR USE WITH BRAIDED HOSES 2.IF USE WITH SPIRAL HOSES ,HOSE FITTINGS SERIES NUMBER IS 20592-XX-XX.

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	A	C	S1
10311-12-04RW	--	M12X1.25	6	04	22	10	14
10311-14-04RW	--	M14X1.5	6	04	23	11	14
10311-16-04RW	--	M16X1.5	6	04	23	11	17
10311-16-05RW	--	M16X1.5	8	05	23	11	17
10311-16-06RW	--	M16X1.5	10	06	22.5	11	17
10311-18-06RW	--	M18X1.5	10	06	22.5	11	19
10311-22-05RW	--	M22X1.5	8	05	26	12	24
10311-22-06RW	--	M22X1.5	10	06	25.5	12	24
10311-22-08RW	10312-22-08RW	M22X1.5	12	08	26.5	12	24
10311-27-10RW	10312-27-10RW	M27X1.5	16	10	30	13	30
10311-30-12RW	10312-30-12RW	M30X1.5	20	12	31	14	32
10311-36-12RW	10312-36-12RW	M36X2	20	12	33	16	38
10311-36-16RW	10312-36-16RW	M36X2	25	16	36.2	16	38
10311-39-16RW	10312-39-16RW	M39X2	25	16	38.2	16	41
10311-45-20RW	10312-45-20RW	M45X2	32	20	42.2	20	46
10311-52-24RW	10312-52-24RW	M52X2	40	24	47	22	55
10311-64-32RW	10312-64-32RW	M64X2	50	32	57.5	27	65

代号 PART NO.		螺纹E	胶管 HOSE BORE		管子外径	尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	TUBE O.D.	A	C	H	S2
20591C-16-04TRW	--	M16X1.5	6	04	8	31.5	3	37.5	19
20591C-18-04TRW	--	M18X1.5	6	04	10	31.5	3	39	22
20591C-20-05TRW	--	M20X1.5	8	05	12	34.5	4.5	42.5	24
20591C-20-06TRW	--	M20X1.5	10	06	12	36.3	4.5	44.8	24
20591C-22-06TRW	--	M22X1.5	10	06	14	36.3	4.5	44.8	27
20591C-24-08TRW	20592C-24-08TRW	M24X1.5	12	08	16	42.5	5	50.5	30
20591C-30-10TRW	20592C-30-10TRW	M30X1.5	16	10	20	57	7	57	36
20591C-36-12TRW	20592C-36-12TRW	M36X2	20	12	25	63.2	6.5	64	41
20591C-42-16TRW	20592C-42-16TRW	M42X2	25	16	30	78.9	9	74	50
20591C-52-20TRW	20592C-52-20TRW	M22X2	32	20	38	92.7	8	88	60

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	A	C	H	S2
20791-10-04RW	--	M10X1	6	04	31.5	7.5	33.5	14
20791-12-04RW	--	M12X1.5	6	04	31.5	10	33.5	17
20791-14-04TRW	--	M14X1.5	6	04	31.5	8.5	32	19
20791-14-05RW	--	M14X1.5	8	05	34.5	8.5	37	19
20791-14-06RW	--	M14X1.5	10	06	36.3	8.5	39.3	19
20791-16-04TRW	--	M16X1.5	6	04	31.5	8	32.5	22
20791-16-05TRW	--	M16X1.5	8	05	34.5	8	35.5	22
20791-16-06RW	--	M16X1.5	10	06	36.3	8	40.3	22
20791-18-05TRW	--	M18X1.5	8	05	34.5	8	36.5	22
20791-18-06RW	--	M18X1.5	10	06	36.3	10	41.3	24
20791-20-06TRW	--	M20X1.5	10	06	36.3	10	39.3	24
20791-20-08RW	20792-20-08RW	M20X1.5	12	08	42.5	10	48	27
20791-22-08TRW	20792-22-08TRW	M22X1.5	12	08	42.5	10	44.5	27
20791-22-10RW	20792-22-10RW	M22X1.5	16	10	57	10	52.5	27
20791-24-08TRW	20792-24-08TRW	M24X1.5	12	08	42.5	11	44.5	30
20791-27-08TRW	20792-27-08TRW	M27X1.5	12	08	42.5	11	46.5	32
20791-27-10TRW	20792-27-10TRW	M27X1.5	16	10	57	11	51	32
20791-30-10TRW	20792-30-10TRW	M30X1.5	16	10	57	11	51.5	36
20791-30-12TRW	20792-30-12TRW	M30X1.5	20	12	63.2	13	58	36
20791-33-12TRW	20792-33-12TRW	M33X2	20	12	63.2	13	57.5	41
20791-36-16TRW	20792-36-16TRW	M36X2	25	16	78.9	14	66	41
20791-39-16TRW	20792-39-16TRW	M39X2	25	16	78.9	14	69	46
20791-42-16TRW	20792-42-16TRW	M42X2	25	16	78.9	15	68	50
20791-42-20WRW	20792-42-20WRW	M42X2	32	20	92.7	15	85.5	50
20791-45-20TRW	20792-45-20TRW	M45X2	32	20	92.7	15	79	55
20791-52-24TRW	20792-52-24TRW	M52X2	40	24	111.4	17	92.5	60

代号 PART NO.		螺纹E	胶管 HOSE BORE		管子外径	O形圈	尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	TUBE O.D.	O RING	A	C	H	S2
20541-14-04TRW	--	M14X1.5	6	04	6	O04.5X1.5	44.1	1.1	20.5	17
20541-16-04TRW	--	M16X1.5	6	04	8	O06.5X1.5	44.5	1.5	20.9	19
20541-16-05TRW	--	M16X1.5	8	05	8	O06.5X1.5	46.6	1.5	21.8	19
20541-18-04TRW	--	M18X1.5	6	04	10	O08.0X1.5	45.6	1.5	22	22
20541-18-06TRW	--	M18X1.5	10	06	10	O08.0X1.5	48.8	1.5	23.6	22
20541-20-06TRW	--	M20X1.5	10	06	12	O10.0X1.5	49.1	2.5	23.9	24
20541-20-08WRW	20542-20-08WRW	M20X1.5	12	08	12	O10.0X1.5	65	2.5	28.6	24
20541-22-06TRW	--	M22X1.5	10	06	14	O11.0X2.0	49.1	2.5	23.9	27
20541-22-08TRW	20542-22-08TRW	M22X1.5	12	08	14	O11.0X2.0	31.8	2.5	25.4	27
20541-24-06TRW	--	M24X1.5	10	06	16	O13.0X2.0	49.1	3	23.9	30
20541-24-08TRW	20542-24-08TRW	M24X1.5	12	08	16	O13.0X2.0	61.8	3	25.4	30
20541-30-10TRW	20542-30-10TRW	M30X2	16	10	20	O16.3X2.4	74.8	2.5	29.5	36
20541-30-12TRW	20542-30-12TRW	M30X2	20	12	20	O16.3X2.4	78.1	2.5	32.3	36
20541-36-12TRW	20542-36-12TRW	M36X2	20	12	25	O20.3X2.4	78.4	3	32.6	46
20541-42-12TRW	20542-42-12TRW	M42X2	20	12	30	O25.3X2.4	79.6	4	33.8	50
20541-42-16TRW	20542-42-16TRW	M42X2	25	16	30	O25.3X2.4	91.8	4	34.5	50
20541-52-20TRW	20542-52-20TRW	M52X2	32	20	38	O33.3X2.4	101.7	4.5	39.8	60
20541-52-24TRW	20542-52-24TRW	M52X2	40	24	38	O33.3X2.4	116.4	4.5	43.7	60

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	A	C	H	S2
20191-10-04RW	--	M10X1	6	04	31.5	2.5	37	14
20191-12-04RW	--	M12X1.5	6	04	31.5	4	37.5	17
20191-12-05RW	--	M12X1.5	8	05	34.5	4	40.5	17
20191-14-04TRW	--	M14X1.5	6	04	31.5	4	36	19
20191-14-05RW	--	M14X1.5	8	05	34.5	4.5	41	19
20191-16-04TRW	--	M16X1.5	6	04	31.5	5	36	22
20191-16-05TRW	--	M16X1.5	8	05	34.5	5	39	22
20191-16-06RW	--	M16X1.5	10	06	36.3	4.5	43.8	22
20191-18-05TRW	--	M18X1.5	8	05	34.5	4	41	22
20191-18-06TRW	--	M18X1.5	10	06	36.3	4	43.3	22
20191-18-08RW	20192-18-08RW	M18X1.5	12	08	42.5	4	51.5	24
20191-20-06TRW	--	M20X1.5	10	06	36.3	5.5	43.8	24
20191-20-08RW	20192-20-08RW	M20X1.5	12	08	42.5	5.5	52	27
20191-22-06TRW	20192-22-06TRW	M22X1.5	10	06	36.3	5	44.3	27
20191-22-08TRW	20192-22-08TRW	M22X1.5	12	08	42.5	5	49.5	27
20191-22-10RW	20192-22-10RW	M22X1.5	16	10	57	5	57.5	27
20191-24-10RW	20192-24-10RW	M24X1.5	16	10	57	5	58.5	30
20191-24-08TRW	20192-24-08TRW	M24X1.5	12	08	42.5	5.5	50	30
20191-27-08DTRW	20192-27-08DTRW	M27X1.5	12	08	42.5	5.5	51	32
20191-27-10DTRW	20192-27-10DTRW	M27X1.5	16	10	57	5.5	55.5	32
20191-27-12DRW	20192-27-12DRW	M27X1.5	20	12	63.2	5.5	66	32
20191-27-10TRW	20192-27-10TRW	M27X2	16	10	57	7	55.5	32
20191-30-12DTRW	20192-30-12DTRW	M30X1.5	20	12	63.2	6	62.5	36
20191-30-12TRW	20192-30-12TRW	M30X2	20	12	63.2	7	62.5	41
20191-36-12TRW	20192-36-12TRW	M36X2	20	12	63.2	8	63.5	41
20191-39-16TRW	20192-39-16TRW	M39X2	25	16	78.9	7	74	46
20191-42-16TRW	20192-42-16TRW	M42X2	25	16	78.9	8.5	74	50
20191-45-20TRW	20192-45-20TRW	M45X2	32	20	92.7	8.5	85.5	55
20191-52-20TRW	20192-52-20TRW	M52X2	32	20	92.7	9	87	60
20191-52-24TRW	20192-52-24TRW	M52X2	40	24	111.4	9	100.5	60
20191-64-32TRW	20192-64-32TRW	M64X2	50	32	138.6	14	122.8	75

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	A	C	H	S2
20291-14-04TRW	--	M14X1.5	6	04	32	8	32	19
20291-14-05RW	--	M14X1.5	8	05	34.5	10	37	19
20291-16-05TRW	--	M16X1.5	8	05	35.5	9	35	22
20291-16-04TRW	--	M16X1.5	6	04	31.5	9	32	22
20291-16-06RW	--	M16X1.5	10	06	36.3	8	40.3	22
20291-18-06TRW	--	M18X1.5	10	06	37.3	10.5	37.8	24
20291-18-04TRW	--	M18X1.5	6	04	31.5	10.5	32.5	24
20291-18-05TRW	--	M18X1.5	8	05	33.5	10.5	35.5	24
20291-20-06TRW	--	M20X1.5	10	06	36.3	10	39.3	24
20291-20-08RW	20292-20-08RW	M20X1.5	12	08	41.5	10	48	27
20291-22-06TRW	--	M22X1.5	10	06	36.3	10	9.3	27
20291-22-08TRW	20292-22-08TRW	M22X1.5	12	08	41.5	10	44.5	27
20291-22-10RW	20292-22-10RW	M22X1.5	16	10	57.5	10	52.5	27
20291-24-08TRW	20292-24-08TRW	M24X1.5	12	08	41.5	11	44.5	30
20291-24-10RW	20292-24-10RW	M24X1.5	16	10	57.5	10.5	53	30
20291-27-10TRW	20292-27-10TRW	M27X1.5	16	10	57.5	10	50.3	32
20291-27-08TRW	20292-27-08TRW	M27X1.5	12	08	41.5	10	45.8	32
20291-27-12RW	20292-27-12RW	M27X1.5	20	12	62.5	10	60.5	32
20291-30-12TRW	20292-30-12TRW	M30X1.5	20	12	62.5	10.5	58	36
20291-30-10TRW	20292-30-10TRW	M30X1.5	16	10	57.5	10.5	51.5	36
20291-33-16RW	20292-33-16RW	M33X1.5	25	16	74.4	13.5	70	41
20291-36-12TRW	20292-36-12TRW	M36X2.0	20	12	62.5	13	59.5	41
20291-36-16TRW	20292-36-16TRW	M36X2.0	25	16	75.9	13	68	41
20291-39-16TRW	20292-39-16TRW	M39X2.0	25	10	79.2	13	53	46
20291-42-16TRW	20292-42-16TRW	M42X2.0	25	16	74.4	15	69	50
20291-45-20TRW	20292-45-20TRW	M45X2.0	32	20	92.7	15	79	55
20291-52-24TRW	20292-52-24TRW	M52X2.0	40	24	111.4	17	92.5	60
20291-60-24TRW	20292-60-24TRW	M60X2.0	40	24	111.4	19	92.5	70
20291-64-32TRW	20292-64-32TRW	M64X2.0	51	32	136.7	23	113.8	75

代号 PART NO.		螺纹E	胶管 HOSE BORE		管子外径	尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	TUBE O.D.	A	C	H	S2
20411C-12-04WRW	--	M12X1.5	6	04	6	45.6	3.5	22	17
20411C-14-04TRW	--	M14X1.5	6	04	8	44.1	3.5	20.5	19
20411C-16-04TRW	--	M16X1.5	6	04	10	44.1	4	20.5	22
20411C-16-05TRW	--	M16X1.5	8	05	10	46.2	4	21.4	22
20411C-16-06WRW	--	M16X1.5	10	06	10	49.9	3.5	24.7	19
20411C-18-06TRW	--	M18X1.5	10	06	12	48.8	3	23.6	22
20411C-22-06TRW	--	M22X1.5	10	06	15	49.1	4.5	23.9	27
20411C-22-08TRW	20412C-22-08TRW	M22X1.5	12	08	15	61.8	4.5	25.4	27
20411C-26-10TRW	20412C-26-10TRW	M26X1.5	16	10	18	73.8	4	28.5	32
20411C-30-10TRW	20412C-30-10TRW	M30X2	16	10	22	73.8	7	28.5	36
20411C-30-12TRW	20412C-30-12TRW	M30X2	20	12	22	77.1	7	31.3	36
20411C-36-16TRW	20412C-36-16TRW	M36X2	25	16	28	89.6	6.5	33.2	41
20411C-45-20TRW	20412C-45-20TRW	M45X2	32	20	35	101.7	7	39.8	50
20411C-52-24TRW	20412C-52-24TRW	M52X2	40	24	42	117.1	8	44.4	60

代号 PART NO.		螺纹E	胶管 HOSE BORE		管子外径	尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	TUBE O.D.	A	C	S2
20511C-16-04TRW	--	M16X1.5	6	04	8	20	3	19
20511C-18-04TRW	--	M18X1.5	6	04	10	21.5	3	22
20511C-20-05TRW	--	M20X1.5	8	05	12	22	4.5	24
20511C-20-06TRW	--	M20X1.5	10	06	12	21.5	4.5	24
20511C-22-06TRW	--	M22X1.5	10	06	14	21.5	4.5	27
20511C-24-08TRW	20512C-24-08TRW	M24X1.5	12	08	16	22	5	30
20511C-30-10TRW	20512C-30-10TRW	M30X1.5	16	10	20	25.5	7	36
20511C-36-12TRW	20512C-36-12TRW	M36X2	20	12	25	25	6.5	41
20511C-42-16TRW	20512C-42-16TRW	M42X2	25	16	30	29.7	9	50
20511C-52-20TRW	20512C-52-20TRW	M52X2	32	20	38	32.7	8	60

代号	螺纹E	软管		尺寸
代号	螺纹E	公称内径	标号	A	C	H	S2
20291-12-02	M12X1.25	4	02	26.5	8	30.5	17
20291-12-04	M12X1.25	6	04	30	8	33.5	17
20291-14-04	M14X1.5	6	04	27.5	8.5	34	19
20291-14-05	M14X1.5	8	05	33	8.5	37	19
20291-16-04	M16X1.5	6	04	30	8	35	22
20291-16-05	M16X1.5	8	05	31	8	39.5	22
20291-16-06	M16X1.5	10	06	35.3	8	40.3	22
20291-18-05T	M18X1.5	8	05	33	8	39	24
20291-18-06	M18X1.5	10	06	33	8	42	24
20291-22-08	M22X1.5	12	08	42.5	10	49.5	27
20291-22-10	M22X1.5	16	10	57.5	10	53	27
20291-24-08T	M24X1.5	12	08	41	11	45.5	30
20291-27-04T	M27X1.5	6	04	30	10	35.5	32
20291-27-08T	M27X1.5	12	08	41	10	46	32
20291-27-10T	M27X1.5	16	10	48.5	10	51.5	32
20291-30-12	M30X1.5	20	12	50.5	11	63.5	36
20291-33-14	M33X2	22	14	71.2	13	65	41
20291-36-14T	M36X2	22	14	57.5	13	64	41
20291-36-16	M36X2	25	16	66	13	76.5	41
20291-39-16T	M39X2	25	16	66	13	72.5	46
20291-42-20W	M42X2	32	20	91.5	15	80.5	50
20291-45-20T	M45X2	32	20	75	15	85	55
20291-52-20T	M52X2	32	20	91.5	17	78.5	60
20291-52-24T	M52X2	40	24	89	17	97	60
20291-60-28T	M60X2	45	28	119.9	20	106.5	70
20291-64-32T	M64X2	50	32	130.95	23	113.3	75
注：1.上诉代号用于编制软管。 2.如需用于缠绕软管代码号改为20292-xx-xx。 NOTE : 1.FOR USE WITH BRAIDED HOSES 2.IF USE WITH SPIRAL HOSES ,HOSE FITTINGS SERIES NUMBER IS 20292-XX-XX.

代号	螺纹E	软管		管子外径	O形圈	尺寸
代号	螺纹E	公称内径	标号	管子外径	O形圈	A	C	H	S2
20491-12-03	M12X1.5	5	03	6	O04.5X1.5	25.6	1	34.5	17
20491-12-04	M12X1.5	6	04	6	O04.5X1.5	27.5	1	43	17
20491-14-04	M14X1.5	6	04	8	O06.5X1.5	27.5	2	44.5	19
20491-16-04	M16X1.5	6	04	10	O08.0X1.5	27.5	2	45	22
20491-16-05	M16X1.5	8	05	10	O08.0X1.5	31	2	49.5	22
20491-16-06	M16X1.5	10	06	10	O08.0X1.5	33	2	50.5	22
20491-18-05T	M18X1.5	8	05	12	O10.0X1.5	31	1.5	43	22
20491-18-06	M18X1.5	10	06	12	O10.0X1.5	33	2.5	52.5	24
20491-22-06T	M22X1.5	10	06	15	O12.0X2.0	33	3	47	27
20491-22-08	M22X1.5	12	08	15	O12.0X2.0	42.5	2.5	62.5	27
20491-26-08T	M26X1.5	12	08	18	O15.0X2.0	42.5	2.1	54.5	32
20491-26-10	M26X1.5	16	10	18	O15.0X2.0	48.5	2.5	68	32
20491-26-12	M26X1.5	20	12	18	O15.0X2.0	50.5	2.5	76	32
20491-30-10T	M30X2	16	10	22	O20.0X2.0	48.5	3.8	59.5	36
20491-30-12	M30X2	20	12	22	O20.0X2.0	50.5	4	78	36
20491-36-12T	M36X2	20	12	28	O26.0X2.0	50.5	4.5	71	46
20491-36-14T	M36X2	22	14	28	O26.0X2.0		4.5		46
20491-45-16T	M45X2	25	16	35	O32.0X2.5	66	4	83	55
20491-45-20T	M45X2	32	20	35	O32.0X2.5	75	4	95	55
20491-52-20T	M52X2	32	20	42	O38.0X2.5	75	4	96.5	60
20491-52-24T	M52X2	40	24	42	O38.0X2.5	89	4	108.5	60
注：1.上诉代号用于编制软管。 2.如需用于缠绕软管代码号改为20492-xx-xx。 NOTE : 1.FOR USE WITH BRAIDED HOSES 2.IF USE WITH SPIRAL HOSES ,HOSE FITTINGS SERIES NUMBER IS 20492-XX-XX.

代号 PART NO.		胶管 HOSE BORE		管子外径	尺寸 DIMENSIONS			备注
编织 BRAIDED	缠绕 SPIRAL	公称内径 DN	标号DASH	TUBE O.D.	A	C	H	NOTE
50091-06-04RW	--	6	04	6	31.5	22	48	轻系列
50091-08-05RW	--	8	05	8	35.5	24	55.5
50091-08-06RW	--	10	06	8	36.8	24	57.5
50091-10-05RW	--	8	05	10	35.5	23	53
50091-10-06RW	--	10	06	10	36.3	23	55.3
50091-12-06RW	--	10	06	12	36.3	23	59.8
50091-12-08RW	50092-12-08RW	12	008	12	41.5	23	67
50091-15-06RW	50092-15-06RW	10	06	15	36.9	25	59.8
50091-15-08RW	50092-15-08RW	12	08	15	41.5	25	65
50091-18-08RW	50092-18-08RW	12	08	18	41.5	26	68.5
50091-18-10RW	50092-18-10RW	16	10	18	58	26	73
50091-22-10RW	50092-22-10RW	16	10	22	58	28	76.5
50091-22-12RW	50092-22-12RW	20	12	22	65.5	28	86
50091-22-16RW	50092-22-16RW	25	16	22	78.9	28	91.5
50091-28-16RW	50092-28-16RW	25	16	28	78.9	30	95.5
50091-35-20RW	50092-35-20RW	32	20	35	92.7	36	112.5
50091-42-24RW	50092-42-24RW	40	24	42	111.5	40	123
50091-08-04RW	--	6	04	8	31.5	24	52.5	重系列
50091-08-05RW	--	8	05	8	35.5	24	55.5
50091-08-06RW	--	10	06	8	36.8	24	57.8
50091-10-04RW	--	6	04	10	31.5	26	53
50091-12-04RW	--	6	04	12	31.5	26	57.5
50091-12-05RW	--	8	05	12	34.5	26	60.5
50091-14-06RW	--	10	06	14	36.3	29	63.8
50091-14-08RW	50092-14-08RW	12	08	14	41.5	29	69
50091-14-12RW	50092-14-12RW	20	12	14	66.2	29	83
50091-16-08RW	50092-16-08RW	12	08	16	41.5	30	73
50091-16-10RW	50092-16-10RW	16	10	16	58	30	77.5
50091-20-10RW	50092-20-10RW	16	10	20	58	36	84.5
50091-20-12RW	50092-20-12RW	20	12	20	65.5	36	95.5
50091-25-12RW	50092-25-12RW	20	12	25	65.5	40	98
50091-25-16RW	50092-25-16RW	25	16	25	78.9	40	103.5
50091-30-16RW	50092-30-16RW	25	16	30	80.2	44	109.5
50091-30-20RW	50092-30-20RW	32	20	30	92.7	44	120.5
50091-38-16RW	50092-38-16RW	25	16	38	78.9	50	115.5
50091-38-20RW	50092-38-20RW	32	20	38	92.7	50	126.5

代号	螺纹E	软管		管子外径	尺寸
代号	螺纹E	公称内径	标号	管子外径	A	C	S2
10411-12-04	M12X1.5	6	04	6	22	10	12
10411-14-04	M14X1.5	6	04	8	22	10	14
10411-14-05	M14X1.5	8	05	8	22	10	14
10411-16-04	M16X1.5	6	04	10	23.5	11	17
10411-16-05	M16X1.5	8	05	10	23.5	11	17
10411-16-06	M16X1.5	10	06	10	23.5	11	17
10411-18-05	M18X1.5	8	05	12	24	11	19
10411-18-06	M18X1.5	10	06	12	24	11	19
10411-22-06	M22X1.5	10	06	15	26.5	12	24
10411-22-08	M22X1.5	12	08	15	27	12	24
10411-26-08	M26X1.5	12	08	18	28.5	12	27
10411-26-10	M26X1.5	16	10	18	29.5	12	27
10411-27-10	M27X1.5	16	10	18	32.5	14	30
10411-30-10	M30X2	16	10	22	33.5	14	32
10411-30-12	M30X2	20	12	22	33.5	14	32
10411-36-16	M36X2	25	16	28	36	14	38
10411-45-20	M45X2	32	20	35	40	16	46
10411-52-24	M52X2	40	24	42	43	16	55
注：1.上诉代号用于编制软管。 2.如需用于缠绕软管代码号改为10412-xx-xx。 NOTE : 1.FOR USE WITH BRAIDED HOSES 2.IF USE WITH SPIRAL HOSES ,HOSE FITTINGS SERIES NUMBER IS 10412-XX-XX.

代号 PART NO.		螺纹E	胶管 HOSE BORE		管子外径	O形圈	尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	TUBE O.D.	O RING	A	C	S1
20411-12-04WRW	--	M12X1.5	6	04	6	O04.5X1.5	23.6	1.4	17
20411-14-04TRW	--	M14X1.5	6	04	8	O06.5X1.5	19.1	1.4	17
20411-14-05WRW	--	M14X1.5	10	06	8	O06.5X1.5	23.7	1.4	17
20411-16-04TRW	--	M16X1.5	6	04	10	O08.0X1.5	19.7	2.1	19
20411-16-05TRW	--	M16X1.5	8	05	10	O08.0X1.5	19.7	2.1	19
20411-16-06WRW	--	M16X1.5	10	06	10	O08.0X1.5	24.5	2.1	19
20411-18-05TRW	--	M18X1.5	8	05	12	O10.0X1.5	21.5	1.5	22
20411-18-06TRW	--	M18X1.5	10	06	12	O10.0X1.5	21	1.5	22
20411-18-08WRW	20412-18-08WRW	M18X1.5	12	08	12	O10.0X1.5	26.2	1.8	22
20411-22-05TRW	--	M22X1.5	8	05	15	O12.0X2.0	22	3	27
20411-22-06TRW	--	M22X1.5	10	06	15	O12.0X2.0	21.5	3	27
20411-22-08TRW	20412-22-08TRW	M22X1.5	12	08	15	O12.0X2.0	22.5	3	27
20411-22-10WRW	20412-22-10WRW	M22X1.5	16	10	15	O12.0X2.0	27.1	3	27
20411-26-08TRW	20412-26-08TRW	M26X1.5	12	08	18	O15.0X2.0	23.4	2.1	32
20411-26-10TRW	20412-26-10TRW	M26X1.5	16	10	18	O15.0X2.0	23.9	2.1	32
20411-26-12WRW	20412-26-12WRW	M26X1.5	20	12	18	O15.0X2.0	27.4	2.1	32
20411-30-10TRW	20412-30-10TRW	M30X2	16	10	22	O20.0X2.0	26.7	3.8	36
20411-30-12TRW	20412-30-12TRW	M30X2	20	12	22	O20.0X2.0	25.7	3.8	36
20411-30-16WRW	20412-30-16WRW	M30X2	25	16	22	O20.0X2.0	32.5	3.8	36
20411-36-12TRW	20412-36-12TRW	M36X2	20	12	28	O26.0X2.0	25	4.5	41
20411-36-16TRW	20412-36-16TRW	M36X2	25	16	28	O26.0X2.0	28.2	4.5	41
20411-36-20WRW	20412-36-20WRW	M36X2	32	20	28	O26.0X2.0	33.3	4.5	41
20411-45-16TRW	20412-45-16TRW	M45X2	25	16	35	O32.0X2.5	31.2	4	50
20411-45-20TRW	20412-45-20TRW	M45X2	32	20	35	O32.0X2.5	31.2	4	50
20411-52-20TRW	20412-52-20TRW	M52X2	32	20	42	O38.0X2.5	32.2	4	60
20411-52-24TRW	20412-52-24TRW	M52X2	40	24	42	O38.0X2.5	33	4	60

代号 PART NO.		螺纹E	胶管 HOSE BORE		管子外径	尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	TUBE O.D.	A	C	H	S2
20541C-16-04TRW	--	M16X1.5	6	04	8	44.5	3	20.9	19
20541C-18-04TRW	--	M18X1.5	6	04	10	45.6	3	22	22
20541C-20-05TRW	--	M20X1.5	8	05	12	48	4.5	23.2	24
20541C-20-06TRW	--	M20X1.5	10	06	12	49.1	4.5	23.9	24
20541C-22-06TRW	--	M22X1.5	10	06	14	49.1	4.5	23.9	27
20541C-24-08TRW	20542C-24-08TRW	M24X1.5	12	08	16	62.2	5	25.8	30
20541C-30-10TRW	20542C-30-10TRW	M30X1.5	16	10	20	73.8	7	28.5	36
20541C-36-12TRW	20542C-36-12TRW	M36X2	20	12	25	77.4	6.5	31.6	41
20541C-42-16TRW	20542C-42-16TRW	M42X2	25	16	30	90.7	9	34.3	50
20541C-52-20TRW	20542C-52-20TRW	M22X2	32	20	38	102.4	8	40.5	60

代号 PART NO.		螺纹E	胶管 HOSE BORE		管子外径	尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	TUBE O.D.	A	C	S1
10511-14-04RW	--	M14X1.5	6	04	6	24	12	14
10511-16-04RW	--	M16X1.5	6	04	8	26	12	17
10511-16-05RW	--	M16X1.5	8	04	8	26	12	17
10511-16-06RW	--	M16X1.5	10	06	8	25.5	12	17
10511-18-05RW	--	M18X1.5	8	05	10	26	12	19
10511-18-06RW	--	M18X1.5	10	06	10	25.5	12	19
10511-20-05RW	--	M20X1.5	8	05	12	28	12	22
10511-20-06RW	--	M20X1.5	10	06	12	27.5	12	22
10511-22-08RW	10512-22-08RW	M20X1.5	12	08	14	30.5	14	24
10511-24-08RW	10512-24-08RW	M24X1.5	12	08	16	30.5	14	27
10511-30-10RW	10512-30-10RW	M30X2	16	10	20	35	16	32
10511-30-12RW	10512-30-12RW	M30X2	20	12	20	34	16	32
10511-36-12RW	10512-36-12RW	M36X2	25	16	25	41.2	18	41
10511-36-16RW	10512-36-16RW	M36X2	25	16	25	41.2	18	41
10511-42-16RW	10512-42-16RW	M42X2	25	16	30	43.2	20	46
10511-42-20RW	10512-42-20RW	M42X2	32	20	30	43.2	20	46
10511-52-20RW	10512-52-20RW	M52X2	32	20	38	48.2	22	55

代号	螺纹E	软管		尺寸
代号	螺纹E	公称内径	标号	A	C	H	S2
20241-14-04	M14X1.5	6	04	38	8.5	19	19
20241-14-05	M14X1.5	8	05	42.7	8.5	19.3	19
20241-16-05	M16X1.5	8	05	42.3	8.5	20.7	22
20241-18-06	M18X1.5	10	06	45.5	8	22	24
20241-22-08	M22X1.5	12	08	57.5	10	24.5	27
20241-27-10T	M27X1.5	16	10	58	10	24.5	32
20241-30-12T	M30X1.5	20	12	74	11	30	36
20241-36-12T	M36X2	20	12	75	13	27.5	41
20241-36-14T	M36X2	22	14	77.3	13	27	41
20241-36-16	M36X2	25	16	85.7	13	31.5	41
20241-39-16T	M39X2	25	16	82	13	30	46
20241-42-20W	M42X2	32	20	95.9	15	35.2	50
20241-45-20T	M45X2	32	20	94.5	15	35.5	55
20241-52-20T	M52X2	32	20	94.5	17	33.8	60
20241-52-24T	M52X2	40	24	105	17	38.5	60
20241-60-28T	M60X2	45	28	118.7	20	43.6	70
20241-62-32T	M64X2	50	32	127.8	23	45.6	75
注：1.上诉代号用于编制软管。 2.如需用于缠绕软管代码号改为20242-xx-xx。 NOTE : 1.FOR USE WITH BRAIDED HOSES 2.IF USE WITH SPIRAL HOSES ,HOSE FITTINGS SERIES NUMBER IS 20242-XX-XX.

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	A	C	H	S2
20741-10-04RW	--	M10X1	6	04	41.7	7.5	18.1	14
20741-12-04RW	--	M12X1.5	6	04	41.7	10	18.1	17
20741-14-04TRW	--	M14X1.5	6	04	40.6	8.5	17	19
20741-14-05RW	--	M14X1.5	8	05	44.1	8.5	19.3	19
20741-14-06RW	--	M14X1.5	10	06	45.2	8.5	20	19
20741-16-04TRW	--	M16X1.5	6	04	41	8	17.4	22
20741-16-05TRW	--	M16X1.5	8	05	43.1	8	18.3	22
20741-16-06RW	--	M16X1.5	10	06	45.9	8	20.7	22
20741-18-05TRW	--	M18X1.5	8	05	43.8	8	19	22
20741-18-06RW	--	M18X1.5	10	06	46.6	10	21.4	24
20741-20-06TRW	--	M20X1.5	10	06	45.2	10	20	24
20741-20-08RW	20742-20-08RW	M20X1.5	12	08	60.4	10	24	27
20741-22-08TRW	20742-22-08TRW	M22X1.5	12	08	57.9	10	21.5	27
20741-22-10RW	20742-22-10RW	M22X1.5	16	10	70.6	10	25.3	27
20741-24-08TRW	20742-24-08TRW	M24X1.5	12	08	57.9	11	21.5	30
20741-27-08TRW	20742-27-08TRW	M27X1.5	12	08	59.3	11	22.9	32
20741-27-10TRW	20742-27-10TRW	M27X1.5	16	10	69.5	11	24.2	32
20741-30-10TRW	20742-30-10TRW	M30X1.5	16	10	69.9	11	24.6	36
20741-30-12TRW	20742-30-12TRW	M30X1.5	20	12	73.2	13	27.4	36
20741-33-12TRW	20742-33-12TRW	M33X2	20	12	72.8	13	27	41
20741-36-16TRW	20742-36-16TRW	M36X2	25	16	85	14	28.6	41
20741-39-16TRW	20742-39-16TRW	M39X2	25	16	87.2	14	30.8	46
20741-42-16TRW	20742-42-16TRW	M42X2	25	16	86.5	15	30.1	50
20741-42-20WRW	20742-42-20WRW	M42X2	32	20	97.8	15	38.7	50
20741-45-20TRW	20742-45-20TRW	M45X2	32	20	96.1	15	34.2	55
20741-52-24TRW	20742-52-24TRW	M52X2	40	24	110.8	17	38.1	60

代号 PART NO.		螺纹E	胶管 HOSE BORE		组合垫	尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	BONDED	A	D	J	K	S1
70011-10-04RW	--	M10X1	6	04	ZHD-10	18.5	17	20	5	14
70011-12-04RW	--	M12X1.5	6	04	ZHD-12	22	20	22	8	17
70011-12-05RW	--	M12X1.5	8	05	ZHD-12	22	20	22	8	17
70011-12-06RW	--	M12X1.5	10	06	ZHD-12	21.5	20	22	8	17
70011-14-04RW	--	M14X1.5	6	04	ZHD-14	22.5	24	24	8	19
70011-14-05RW	--	M14X1.5	8	05	ZHD-14	22.5	24	24	8	19
70011-14-06RW	--	M14X1.5	10	06	ZHD-14	22	24	24	8	19
70011-16-04RW	--	M16X1.5	6	04	ZHD-16	22	28	26	8	22
70011-16-05RW	--	M16X1.5	8	05	ZHD-16	22	28	26	8	22
70011-16-06RW	--	M16X1.5	10	06	ZHD-16	21.5	28	26	8	22
70011-18-04RW	--	M18X1.5	6	04	ZHD-18	24.5	32	30	8	24
70011-18-05RW	--	M18X1.5	8	05	ZHD-18	25.5	32	30	8	24
70011-18-06RW	--	M18X1.5	10	06	ZHD-18	25	32	30	8	24
70011-18-08RW	70012-18-08RW	M18X1.5	12	08	ZHD-18	25	32	30	8	24
70011-22-06RW	--	M22X1.5	10	06	ZHD-22	29.1	39	36	10	27
70011-22-08RW	70012-22-08RW	M22X1.5	12	08	ZHD-22	29	39	36	10	27
70011-22-10RW	70012-22-10RW	M22X1.5	16	10	ZHD-22	29.5	39	36	10	27
70011-26-12RW	70012-26-12RW	M26X1.5	20	12	ZHD-26	32.5	46	41	11	32
70011-30-16RW	70012-30-16RW	M30X1.5	25	16	ZHD-30	39.2	54	47	11	36
70011-30-20RW	70012-30-20RW	M30X1.5	32	20	ZHD-30	41.2	54	47	11	36

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	A	C	H	S2
20141-10-04RW	--	M10X1	6	04	44.1	2.5	20.5	14
20141-12-04RW	--	M12X1.5	6	04	44.5	4	20.9	17
20141-12-05RW	--	M12X1.5	8	05	46.6	4	21.8	17
20141-14-04TRW	--	M14X1.5	6	04	43.4	4	19.8	19
20141-14-05RW	--	M14X1.5	8	05	47	4.5	22.2	19
20141-16-04TRW	--	M16X1.5	6	04	43.4	5	19.8	22
20141-16-05TRW	--	M16X1.5	8	05	45.5	5	20.7	22
20141-16-06RW	--	M16X1.5	10	06	48.4	4.5	23.2	22
20141-18-05TRW	--	M18X1.5	8	05	47	4	22.2	22
20141-18-06TRW	--	M18X1.5	10	06	48.1	4	22.9	22
20141-18-08RW	20142-18-08RW	M18X1.5	12	08	62.9	4	26.5	24
20141-20-06TRW	--	M20X1.5	10	06	48.4	5.5	23.2	24
20141-20-08RW	20142-20-08RW	M20X1.5	12	08	63.2	5.5	26.8	27
20141-22-06TRW	20142-22-06TRW	M22X1.5	10	06	48.8	5	23.6	27
20141-22-08TRW	20142-22-08TRW	M22X1.5	12	08	61.5	5	25.1	27
20141-22-10RW	20142-22-10RW	M22X1.5	16	10	74.1	5	28.8	27
20141-24-10RW	20142-24-10RW	M24X1.5	16	10	74.8	5	29.5	30
20141-24-08TRW	20142-24-08TRW	M24X1.5	12	08	61.8	5.5	25.4	30
20141-27-08DTRW	20142-27-08DTRW	M27X1.5	12	08	62.5	5.5	26.1	32
20141-27-10DTRW	20142-27-10DTRW	M27X1.5	16	10	72.7	5.5	27.4	32
20141-27-12DRW	20142-27-12DRW	M27X1.5	20	12	78.8	5.5	33	32
20141-27-10TRW	20142-27-10TRW	M27X2	16	10	72.7	7	27.4	32
20141-30-12DTRW	20142-30-12DTRW	M30X1.5	20	12	76.4	6	30.6	36
20141-30-12TRW	20142-30-12TRW	M30X2	20	12	76.4	7	30.6	41
20141-36-12TRW	20142-36-12TRW	M36X2	20	12	77.1	8	31.3	41
20141-39-16TRW	20142-39-16TRW	M39X2	25	16	90.7	7	34.3	46
20141-42-16TRW	20142-42-16TRW	M42X2	25	16	90.7	8.5	34.3	50
20141-45-20TRW	20142-45-20TRW	M45X2	32	20	100.6	8.5	38.7	55
20141-52-20TRW	20142-52-20TRW	M52X2	32	20	101.7	9	39.8	60
20141-52-24TRW	20142-52-24TRW	M52X2	40	24	116.4	9	43.7	60
20141-64-32TRW	20142-64-32TRW	M64X2	50	32	142.1	14	52.3	75

代号 PART NO.		螺纹E	胶管 HOSE BORE		管子外径	O形圈	尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	TUBE O.D.	O RING	A	C	H	S2
20591-14-04TRW	--	M14X1.5	6	04	6	O04.5X1.5	31.5	1.1	36.9	17
20591-16-04TRW	--	M16X1.5	6	04	8	O06.5X1.5	31.5	1.5	37.5	19
20591-16-05TRW	--	M16X1.5	8	05	8	O06.5X1.5	34.5	1.5	40.5	19
20591-18-04TRW	--	M18X1.5	6	04	10	O08.0X1.5	31.5	1.5	39	22
20591-18-06TRW	--	M18X1.5	10	06	10	O08.0X1.5	36.3	1.5	44.3	22
20591-20-06TRW	--	M20X1.5	10	06	12	O10.0X1.5	36.3	2.5	44.8	24
20591-20-08WRW	20592-20-08WRW	M20X1.5	12	08	12	O10.0X1.5	42.5	2.5	54.5	24
20591-22-06TRW	--	M22X1.5	10	06	14	O11.0X2.0	36.3	2.5	44.8	27
20591-22-08TRW	20592-22-08TRW	M22X1.5	12	08	14	O11.0X2.0	42.5	2.5	50	27
20591-24-06TRW	--	M24X1.5	10	06	16	O13.0X2.0	36.3	3	44.8	30
20591-24-08TRW	20592-24-08TRW	M24X1.5	12	08	16	O13.0X2.0	42.5	3	50	30
20591-30-10TRW	20592-30-10TRW	M30X2	16	10	20	O16.3X2.4	57	2.5	58.5	36
20591-30-12TRW	20592-30-12TRW	M30X2	20	12	20	O16.3X2.4	63.2	2.5	65	36
20591-36-12TRW	20592-36-12TRW	M36X2	20	12	25	O20.3X2.4	63.2	3	65.3	46
20591-42-12TRW	20592-42-12TRW	M42X2	20	12	30	O25.3X2.4	63.2	4	67.1	50
20591-42-16TRW	20592-42-16TRW	M42X2	25	16	30	O25.3X2.4	78.9	4	75.6	50
20591-52-20TRW	20592-52-20TRW	M52X2	32	20	38	O33.3X2.4	92.7	4.5	87	60
20591-52-24TRW	20592-52-24TRW	M52X2	40	24	38	O33.3X2.4	111.4	4.5	100.5	60

代号 PART NO.		螺纹E	胶管 HOSE BORE		管子外径	尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	TUBE O.D.	A	C	H	S2
20491C-12-04WRW	--	M12X1.5	6	04	6	31.5	3.5	39	17
20491C-14-04TRW	--	M14X1.5	6	04	8	31.5	3.5	37	19
20491C-16-04TRW	--	M16X1.5	6	04	10	31.5	4	37	22
20491C-16-05TRW	--	M16X1.5	8	05	10	34.5	4	40	22
20491C-16-06WRW	--	M16X1.5	10	06	10	36.3	3.5	45.9	19
20491C-18-06TRW	--	M18X1.5	10	06	12	36.3	3	44.3	22
20491C-22-06TRW	--	M22X1.5	10	06	15	36.3	4.5	44.8	27
20491C-22-08TRW	20492C-22-08TRW	M22X1.5	12	08	15	42.5	4.5	50	27
20491C-26-10TRW	20492C-26-10TRW	M26X1.5	16	10	18	57	4	57	32
20491C-30-10TRW	20492C-30-10TRW	M30X2	16	10	22	57	7	57	36
20491C-30-12TRW	20492C-30-12TRW	M30X2	20	12	22	63.2	7	63.5	36
20491C-36-16TRW	20492C-36-16TRW	M36X2	25	16	28	78.9	6.5	72.5	41
20491C-45-20TRW	20492C-45-20TRW	M45X2	32	20	35	92.7	7	87	55
20491C-52-24TRW	20492C-52-24TRW	M52X2	40	24	42	111.4	8	101.5	60

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	A	C	H	S2
22611D-04-04SMRW	--	G1/4”X19	6	04	23	5.5	12	19
22611D-06-06SMRW	--	G3/8”X19	10	06	23.7	6.3	17	22
22611D-08-08SMRW	22612D-08-08SMRW	G1/2”X14	12	08	28.5	7.5	22	27
22611D-10-10SMRW	22612D-10-10SMRW	G5/8”X14	10	06	28	9.5	22	30
22611D-12-12SMRW	22612D-12-12SMRW	G3/4”X14	20	12	31.1	10.9	27	32
22611D-16-16SMRW	22612D-16-16SMRW	G1”X11	25	16	36.5	11.7	32	41
22611D-20-20SMRW	22612D-20-20SMRW	G1.1/4”X11	32	20	42.7	11	41	50
22611D-24-24SMRW	22612D-24-24SMRW	G1.1/2”X11	40	24	43	13	46	55
22611D-32-32SMRW	22612D-32-32SMRW	G2”X11	50	32	49	16	55	70

代号	螺纹E	软管		管子外径	O形圈	尺寸
代号	螺纹E	公称内径	标号	管子外径	O形圈	A	C	H	S2
20441-12-04	M14X1.5	6	04	8	O06.5X1.5	45	2	26	19
20441-16-05	M16X1.5	8	05	10	O08.5X1.5	49.5	2	27.8	22
20441-16-06	M16X1.5	10	06	10	O08.5X1.5	51.3	2	27.8	22
20441-18-05T	M18X1.5	8	05	12	O10.0X1.5	44.7	1.5	23.2	22
20441-18-06	M18X1.5	10	06	12	O10.0X1.5	53	2.5	29	24
20441-22-05T	M22X1.5	8	05	15	O12.0X2		3		27
20441-22-06T	M22X1.5	10	06	15	O12.0X2	49	3	25.3	27
20441-22-08	M22X1.5	12	08	15	O12.0X2	66.5	2.5	34	27
20441-26-08T	M26X1.5	12	08	18	O15.0X2	61	2.1	28	32
20441-26-10	M26X1.5	16	10	18	O15.0X2	70	2.5	36	32
20441-26-12	M26X1.5	20	12	18	O15.0X2		2.5		32
20441-30-10T	M30X1.5	16	10	22	O20.0X2	64	3.8	30	36
20441-30-12	M30X1.5	20	12	22	O20.0X2	84.5	4	40.5	36
20441-36-12T	M36X1.5	20	12	28	O28.0X2	79.3	4.5	35.5	46
20441-36-14T	M36X2	22	14	28	O28.0X2		4.5		46
20441-45-20T	M45X2	32	20	35	O35.0X2	101.8	4	42.4	55
20441-52-20T	M52X2	32	20	42	O42.0X2		4	46.6	60
20441-52-24T	M52X2	40	24	42	O42.0X2	113	4		60
注：1.上诉代号用于编制软管。 2.如需用于缠绕软管代码号改为20441-xx-xx。 NOTE : 1.FOR USE WITH BRAIDED HOSES 2.IF USE WITH SPIRAL HOSES ,HOSE FITTINGS SERIES NUMBER IS 20441-XX-XX.

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREAD E	公称内径 DN	标号DASH	A	C	H	S1	S2
28641-14-04RW	--	M14X1.5	6	04	44.9	10.5	21.3	19	19
28641-16-05RW	--	M16X1.5	8	05	49.1	10	24.3	22	22
28641-18-06RW	--	M18X1.5	10	06	50.9	11.5	25.7	24	24
28641-20-08RW	28642-20-08RW	M20X1.5	12	08	63.9	12	27.5	27	27
28641-22-08RW	28642-22-08RW	M22X1.5	12	08	63.9	14	27.5	27	27
28641-24-10RW	28642-24-10RW	M24X1.5	16	10	75.9	15	30.6	32	32
28641-30-12RW	28642-30-12RW	M30X1.5	20	12	79.9	18.3	34.1	36	36
28641-33-16RW	28642-33-16RW	M33X1.5	25	16	92.1	21.3	35.7	41	41
28641-36-20RW	28642-36-20RW	M36X1.5	32	20	103.8	20	41.9	46	46
28641-42-24WRW	28642-42-24WRW	M42X1.5	40	24	122.4	18.8	49.7	55	55

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREAD E	公称内径 DN	标号DASH	A	C	H	S1	S2
28691-14-04RW	--	M14X1.5	6	04	31.5	10.5	38	19	19
28691-16-05RW	--	M16X1.5	8	05	34.5	10	44	22	22
28691-18-06RW	--	M18X1.5	10	06	36.3	11.5	47.3	24	24
28691-20-08RW	28692-20-08RW	M20X1.5	12	08	42.5	12	53	27	27
28691-22-08RW	28692-22-08RW	M22X1.5	12	08	42.5	14	53	27	27
28691-24-10RW	28692-24-10RW	M24X1.5	16	10	57	15	60	32	32
28691-30-12RW	28692-30-12RW	M30X1.5	20	12	63.2	18.3	67.5	36	36
28691-33-16RW	28692-33-16RW	M33X1.5	25	16	78.9	21.3	76	41	41
28691-36-20RW	28692-36-20RW	M36X1.5	32	20	92.7	20	90	46	46
28691-42-24WRW	28692-42-24WRW	M42X1.5	40	24	111.4	18.8	109	55	55

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREAD E	公称内径 DN	标号DASH	A	C	S2
18611-14-04RW	--	M14X1.5	6	04	29	17	17
18611-14-06RW	--	M14X1.5	10	06	28.5	17	17
18611-16-04RW	--	M16X1.5	6	04	30	18	17
18611-16-06RW	--	M16X1.5	10	06	29.5	18	17
18611-18-06RW	--	M18X1.5	10	06	29.5	18	19
18611-20-08RW	18612-20-08RW	M20X1.5	12	08	34.5	20	22
18611-22-08RW	18612-22-08RW	M22X1.5	12	08	34.5	20	24
18611-24-10RW	18612-24-10RW	M24X1.5	16	10	38.5	21.5	27
18611-32-12RW	18612-32-12RW	M30X1.5	20	12	43	26	32
18611-33-16RW	18612-33-16RW	M33X1.5	25	16	50.2	30	36
18611-36-20RW	18612-36-20RW	M36X1.5	32	20	53.2	33	38
18611-42-24RW	18612-42-24RW	M42X1.5	40	24	59	36	46

代号	螺纹E	软管		尺寸
代号	螺纹E	公称内径	标号	A	C	S2
20711-10-02	M10X1	4	02	14	7.5	14
20711-12-03C	M12X1.25	5	03	14	9	17
20711-12-03	M12X1.5	5	03	14	10	17
20711-12-04	M12X1.5	6	04	15	10	17
20711-14-04	M14X1.5	6	04	16	8.5	19
20711-14-05	M14X1.5	8	05	15.5	8.5	19
20711-14-06	M14X1.5	10	06	15.5	8.5	19
20711-16-04	M16X1.5	6	04	16.5	8	22
20711-16-05	M16X1.5	8	05	17	8	22
20711-16-06	M16X1.5	10	06	16	8	22
20711-18-05T	M18X1.5	8	05	16	8	22
20711-18-06	M18X1.5	10	06	18.5	10	24
20711-20-06T	M20X1.5	10	06	16	10	24
20711-20-08	M20X1.5	12	08	18.5	10	27
20711-22-06T	M22X1.5	10	06	16	10	27
20711-22-08	M22X1.5	12	08	19.5	10	27
20711-22-10	M22X1.5	16	10	19	10	27
20711-24-08T	M24X1.5	12	08	16.5	11	30
20711-27-08T	M27X1.5	12	08	18.5	11	32
20711-27-10T	M27X1.5	16	10	21	11	32
20711-27-12	M27X1.5	20	12	21.5	11	32
20711-30-10T	M30X1.5	16	10	18	11	36
20711-30-12	M30X1.5	20	12	22	11	36
20711-33-10T	M33X2	16	10	19.5	13	41
20711-33-12T	M33X2	20	12	20	13	41
20711-33-14	M33X2	22	14	21.5	13	41
20711-36-12T	M36X2	20	12	20	14	41
20711-36-14T	M36X2	22	14	24	14	41
20711-36-16	M36X2	25	16	23	14	41
20711-39-16T	M39X2	25	16	25	14	46
20711-42-16T	M42X2	25	16	23.5	15	50
20711-42-20W	M42X2	32	20	24.5	15	50
20711-45-20T	M45X2	32	20	27	15	55
20711-52-24T	M52X2	40	24	27	17	60
注：1.上诉代号用于编制软管。 2.如需用于缠绕软管代码号改为20712-xx-xx。 NOTE : 1.FOR USE WITH BRAIDED HOSES 2.IF USE WITH SPIRAL HOSES ,HOSE FITTINGS SERIES NUMBER IS 20712-XX-XX.

代号 PART NO.		螺纹E	胶管 HOSE BORE		管子外径	O形圈	尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	TUBE O.D.	O RING	A	C	S1
20511-14-04TRW	--	M14X1.5	6	04	6	O04.5X1.5	19.4	1.1	17
20511-16-04TRW	--	M16X1.5	6	04	8	O06.5X1.5	20	1.5	19
20511-16-05TRW	--	M16X1.5	8	05	8	O06.5X1.5	20	1.5	19
20511-18-04TRW	--	M18X1.5	6	04	10	O08.0X1.5	21.5	1.5	22
20511-18-06TRW	--	M18X1.5	10	06	10	O08.0X1.5	21	1.5	22
20511-20-06TRW		M20X1.5	10	06	12	O10.0X1.5	21.5	2.5	24
20511-20-08WRW	20512-20-08WRW	M20X1.5	12	08	12	O10.0X1.5	27	2.5	24
20511-22-06TRW	--	M22X1.5	10	06	14	O11.0X1.5	21.5	2.5	27
20511-22-08TRW	20512-22-08TRW	M22X1.5	12	08	14	O11.0X1.5	22.5	2.5	27
20511-24-06TRW	--	M24X1.5	10	06	16	O13.0X1.5	21.5	3	30
20511-24-08TRW	20512-24-08TRW	M24X1.5	12	08	16	O13.0X1.5	22.5	3	30
20511-30-10TRW	20512-30-10TRW	M30X2	16	10	20	O16.3X2.4	27	2.5	36
20511-30-12TRW	20512-30-12TRW	M30X2	20	12	20	O16.3X2.4	26	2.5	36
20511-36-12TRW	20512-36-12TRW	M36X2	20	12	25	O20.3X2.4	26.3	3	46
20511-42-12TRW	20512-42-12TRW	M42X2	20	12	30	O25.3X2.4	28.1	4	50
20511-42-16TRW	20512-42-13TRW	M42X2	25	16	30	O25.3X2.4	31.3	4	50
20511-52-20TRW	20512-52-20TRW	M52X2	32	20	38	O33.3X2.4	31.7	4.5	60
20511-52-24TRW	20512-52-24TRW	M52X2	40	24	38	O33.3X2.4	32.5	4.5	60

代号 PART NO.		螺纹E	胶管 HOSE BORE		管子外径	尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	TUBE O.D.	A	C	S2
20411C-12-04WRW	--	M12X1.5	6	04	6	22	3.5	17
20411C-14-04TRW	--	M14X1.5	6	04	8	19.5	3.5	19
20411C-16-04TRW	--	M16X1.5	6	04	10	19.5	4	22
20411C-16-05TRW	--	M16X1.5	8	05	10	19.5	4	22
20411C-16-06WRW	--	M16X1.5	10	06	10	23.6	3.5	19
20411C-18-06TRW	--	M18X1.5	10	06	12	21	3	22
20411C-22-06TRW	--	M22X1.5	10	06	15	21.5	4.5	27
20411C-22-08TRW	20412C-22-08TRW	M22X1.5	12	08	15	22.5	4.5	27
20411C-26-10TRW	20412C-26-10TRW	M26X1.5	16	10	18	25.5	4	32
20411C-30-10TRW	20412C-30-10TRW	M30X2	16	10	22	25.5	7	36
20411C-30-12TRW	20412C-30-12TRW	M30X2	20	12	22	24.5	7	36
20411C-36-16TRW	20412C-36-16TRW	M36X2	25	16	28	28.2	6.5	41
20411C-45-20TRW	20412C-45-20TRW	M45X2	32	20	35	31.7	7	50
20411C-52-24TRW	20412C-52-24TRW	M52X2	40	24	42	33.5	8	60

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	A	C	H	S2
20241-14-04TRW	--	M14X1.5	6	04	40.6	8	17	19
20241-14-05RW	--	M14X1.5	8	05	44.1	10	19.3	19
20241-16-04TRW	--	M16X1.5	6	04	40.6	9	17	22
20241-16-05TRW	--	M16X1.5	8	05	42.7	9	17.9	22
20241-16-06RW	--	M16X1.5	10	06	45.9	8	20.7	22
20241-18-04TRW	--	M18X1.5	6	04	41	10.5	17.4	24
20241-18-05TRW	--	M18X1.5	8	05	43.1	10.5	18.3	24
20241-18-06TRW	--	M18X1.5	10	06	44.2	10.5	19	24
20241-20-06TRW	--	M20X1.5	10	06	45.2	10	20	24
20241-20-08RW	20242-20-08RW	M20X1.5	12	08	60.4	10	24	27
20241-22-06TRW	--	M22X1.5	10	06	45.2	10	20	27
20241-22-08TRW	20242-22-08TRW	M22X1.5	12	08	57.9	10	21.5	27
20241-22-10RW	20242-22-10RW	M22X1.5	16	10	70.6	10	25.3	27
20241-24-08TRW	20242-24-08TRW	M24X1.5	12	08	57.9	11	21.5	30
20241-24-10RW	20242-24-10RW	M24X1.5	16	10	71	10.5	25.7	30
20241-27-08TRW	20242-27-08TRW	M27X1.5	12	08	58.8	10	22.4	32
20241-27-10TRW	20242-27-10TRW	M27X1.5	16	10	59	10	23.7	32
20241-27-12RW	20242-27-12RW	M27X1.5	20	12	75	10	29.2	32
20241-30-10TRW	20242-30-10TRW	M30X1.5	16	10	69.9	10.5	24.6	36
20241-30-12TRW	20242-30-12TRW	M30X1.5	20	12	73.2	10.5	27.4	36
20241-33-16RW	20242-33-16RW	M33X1.5	25	16	87.9	13.5	31.5	41
20241-36-12TRW	20242-36-12TRW	M36X2.0	20	12	74.3	13	28.5	41
20241-36-16TRW	20242-36-16TRW	M36X2.0	25	16	86.5	13	30.1	41
20241-39-16TRW	20242-39-16TRW	M39X2.0	25	16	86.5	13	30.1	46
20241-42-16TRW	20242-42-16TRW	M42X2.0	25	16	87.2	15	30.8	50
20241-45-20TRW	20242-45-20TRW	M45X2.0	32	20	96.1	15	34.2	55
20241-52-24TRW	20242-52-24TRW	M52X2.0	40	24	110.8	17	38.1	60
20241-60-24TRW	20242-60-24TRW	M60X2.0	40	24	110.8	19	38.1	70
20241-64-32TRW	20242-64-32TRW	M64X2.0	51	32	135.8	23	46	75

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	A	C	S2
20111-10-04RW	--	M10X1	6	04	20	2.5	14
20111-12-04RW	--	M12X1.5	6	04	20.5	4	17
20111-12-05RW	--	M12X1.5	8	05	20.5	4	17
20111-14-04TRW	--	M14X1.5	6	04	18.5	4	19
20111-14-05RW	--	M14X1.5	8	05	21	4.5	19
20111-16-04TRW	--	M16X1.5	6	04	18.5	5	22
20111-16-05TRW	--	M16X1.5	8	05	18.5	5	22
20111-16-06RW	--	M16X1.5	10	06	21.5	4.5	22
20111-18-05TRW	--	M18X1.5	8	05	20.5	4	22
20111-18-06TRW	--	M18X1.5	10	06	20	4	22
20111-18-08RW	20112-18-08RW	M18X1.5	12	08	24	4	24
20111-20-06TRW	--	M20X1.5	10	06	20.5	5.5	24
20111-20-08RW	20112-20-08RW	M20X1.5	12	08	24.5	5.5	27
20111-22-06TRW	20112-22-06TRW	M22X1.5	10	06	21	5	27
20111-22-08TRW	20112-22-08TRW	M22X1.5	12	08	22	5	27
20111-22-10RW	20112-22-10RW	M22X1.5	16	10	26	5	27
20111-24-10RW	20112-24-10RW	M24X1.5	16	10	27	5	30
20111-24-08TRW	20112-24-08TRW	M24X1.5	12	08	22.5	5.5	30
20111-27-08DTRW	20112-27-08DTRW	M27X1.5	12	08	23.5	5.5	32
20111-27-10DTRW	20112-27-10DTRW	M27X1.5	16	10	24	5.5	32
20111-27-12DRW	20112-27-12DRW	M27X1.5	20	12	27.5	5.5	32
20111-27-10TRW	20112-27-10TRW	M27X2	16	10	24	7	32
20111-30-12DTRW	20112-30-12DTRW	M30X1.5	20	12	23.5	6	36
20111-30-12TRW	20112-30-12TRW	M30X2	20	12	23.5	7	41
20111-36-12TRW	20112-36-12TRW	M36X2	20	12	24.5	8	41
20111-39-16TRW	20112-39-16TRW	M39X2	25	16	29.7	7	46
20111-42-16TRW	20112-42-16TRW	M42X2	25	16	29.7	8.5	50
20111-45-20TRW	20112-45-20TRW	M45X2	32	20	30.2	8.5	55
20111-52-20TRW	20112-52-20TRW	M52X2	32	20	31.7	9	60
20111-52-24TRW	20112-52-24TRW	M52X2	40	24	32.5	9	60
20111-64-32TRW	20112-64-32TRW	M64X2	50	32	38	14	75

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	A	C	S2
20711-10-04RW	--	M10X1	6	04	16.5	7.5	14
20711-12-04RW	--	M12X1.5	6	04	16.5	10	17
20711-14-04TRW	--	M14X1.5	6	04	14.5	8.5	19
20711-14-05RW	--	M14X1.5	8	05	17	8.5	19
20711-14-06RW	--	M14X1.5	10	06	17	8.5	19
20711-16-04TRW	--	M16X1.5	6	04	15	8	22
20711-16-05TRW	--	M16X1.5	8	05	15	8	22
20711-16-06RW	--	M16X1.5	10	06	18	8	22
20711-18-05TRW	--	M18X1.5	8	05	16	8	22
20711-18-06RW	--	M18X1.5	10	06	19	10	24
20711-20-06TRW	--	M20X1.5	10	06	16	10	24
20711-20-08RW	20712-20-08RW	M20X1.5	12	08	20.5	10	27
20711-22-08TRW	20712-22-08TRW	M22X1.5	12	08	17	10	27
20711-22-10RW	20712-22-10RW	M22X1.5	16	10	21	10	27
20711-24-08TRW	20712-24-08TRW	M24X1.5	12	08	17	11	30
20711-27-08TRW	20712-27-08TRW	M27X1.5	12	08	19	11	32
20711-27-10TRW	20712-27-10TRW	M27X1.5	16	10	19.5	11	32
20711-30-10TRW	20712-30-10TRW	M30X1.5	16	10	20	11	36
20711-30-12TRW	20712-30-12TRW	M30X1.5	20	12	19	13	36
20711-33-12TRW	20712-33-12TRW	M33X2	20	12	18.5	13	41
20711-36-16TRW	20712-36-16TRW	M36X2	25	16	21.7	14	41
20711-39-16TRW	20712-39-16TRW	M39X2	25	16	24.7	14	46
20711-42-16TRW	20712-42-16TRW	M42X2	25	16	23.7	15	50
20711-42-20WRW	20712-42-20WRW	M42X2	32	20	30.2	15	50
20711-45-20TRW	20712-45-20TRW	M45X2	32	20	23.7	15	55
20711-52-24TRW	20712-52-24TRW	M52X2	40	24	24.5	17	60

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	A	C	S2
20211-14-04TRW	--	M14X1.5	6	04	14.5	8	19
20211-14-05TRW	--	M14X1.5	8	05	17	10	19
20211-16-04TRW	--	M16X1.5	6	04	14.5	9	22
20211-16-05TRW	--	M16X1.5	8	05	14.5	9	22
20211-16-06RW	--	M16X1.5	10	06	18	8	22
20211-18-04TRW	--	M18X1.5	6	04	15	10.5	24
20211-18-05TRW	--	M18X1.5	8	05	15	10.5	24
20211-18-06TRW	--	M18X1.5	10	06	14.5	10.5	24
20211-20-06TRW	--	M20X1.5	10	06	16	10	24
20211-20-08RW	20212-20-08RW	M20X1.5	12	08	20.5	10	27
20211-22-06TRW	--	M22X1.5	10	06	16	10	27
20211-22-08TRW	20212-22-08TRW	M22X1.5	12	08	17	10	27
20211-22-10RW	20212-22-10RW	M22X1.5	16	10	21	10	27
20211-24-08TRW	20212-24-08TRW	M24X1.5	12	08	17	11	30
20211-24-10RW	20212-24-10RW	M24X1.5	16	10	21.5	10.5	30
20211-27-08TRW	20212-27-08TRW	M27X1.5	12	08	18.3	10	32
20211-27-10TRW	20212-27-10TRW	M27X1.5	16	10	18.8	10	32
20211-27-12RW	20212-27-12RW	M27X1.5	20	12	22	10	32
20211-30-10TRW	20212-30-10TRW	M30X1.5	16	10	20	10.5	36
20211-30-12TRW	20212-30-12TRW	M30X1.5	20	12	19	10.5	36
20211-36-12TRW	20212-36-12TRW	M36X2.0	20	12	20.5	13	41
20211-36-16TRW	20212-36-16TRW	M36X2.0	25	16	23.7	13	41
20211-39-16TRW	20212-39-16TRW	M39X2.0	25	16	23.7	13	46
20211-42-16TRW	20212-42-16TRW	M42X2.0	25	16	24.7	15	50
20211-45-20TRW	20212-45-20TRW	M45X2.0	32	20	23.7	15	55
20211-52-24TRW	20212-52-24TRW	M52X2.0	40	24	24.5	17	60
20211-60-24TRW	20212-60-24TRW	M60X2.0	40	24	24.5	19	70
20211-64-32TRW	20212-64-32TRW	M64X2.0	51	32	29	23	75

代号	螺纹E	软管		尺寸
代号	螺纹E	公称内径	标号	A	C	S2
20211-10-02	M10X1	4	02	14	6	14
20211-12-03	M12X1.25	5	03	14	8	17
20211-14-04	M14X1.5	6	04	16	8.5	19
20211-14-05	M14X1.5	8	05	15.5	8.5	19
20211-16-04	M16X1.5	6	04	16.5	8	22
20211-16-05	M16X1.5	8	05	17	8	22
20211-16-06	M16X1.5	10	06	16.5	8	22
20211-18-05T	M18X1.5	8	05	17.5	8	24
20211-18-06	M20X1.5	10	06	18.5	8	24
20211-20-06T	M20X1.5	10	06	16	10	24
20211-20-08	M20X1.5	12	08	18.5	10	27
20211-22-06T	M22X1.5	10	06	16	10	27
20211-22-08	M22X1.5	12	08	19.5	10	27
20211-22-10	M22X1.5	16	10	19.5	10	27
20211-24-08T	M24X1.5	12	08	16.5	11	30
20211-24-10	M24X1.5	16	10	20.5	10.5	30
20211-27-08T	M27X1.5	12	08	18.5	10	32
20211-27-10T	M27X1.5	16	10	21	10	32
20211-30-12	M30X1.5	20	12	22	11	36
20211-33-14	M33X2	22	14	21.5	13	41
20211-36-12T	M36X2	20	12	24	13	41
20211-36-14T	M36X2	22	14	24	13	41
20211-39-16T	M39X2	25	16	25	13	46
20211-42-20W	M42X2	32	20	25	15	50
20211-45-20T	M45X2	32	20	27	15	55
20211-52-24T	M52X2	40	24	27	17	60
20211-60-28T	M60X2	45	28	26	20	70
20211-64-32T	M64X2	50	32	26	23	75
注：1.上诉代号用于编制软管。 2.如需用于缠绕软管代码号改为20212-xx-xx。 NOTE : 1.FOR USE WITH BRAIDED HOSES 2.IF USE WITH SPIRAL HOSES ,HOSE FITTINGS SERIES NUMBER IS 20212-XX-XX.

代号 PART NO.		螺纹E	胶管 HOSE BORE		管子外径	O形圈	尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	TUBE O.D.	O RING	A	C	H	S2
20491-12-04WRW	--	M12X1.5	6	04	6	O04.5X1.5	31.5	1.4	40.6	17
20491-14-04TRW	--	M14X1.5	6	04	8	O06.5X1.5	31.5	1.4	36.6	17
20491-14-06WRW	--	M14X1.5	10	06	8	O06.5X1.5	36.3	1.4	46	17
20491-16-04TRW	--	M16X1.5	6	04	10	O08.0X1.5	31.5	0.8	37.2	19
20491-16-05TRW	--	M16X1.5	8	05	10	O08.0X1.5	34.5	0.8	40.2	19
20491-16-06WRW	--	M16X1.5	10	06	10	O08.0X1.5	36.3	2.1	46.8	19
20491-18-05TRW	--	M18X1.5	8	05	12	O10.0X1.5	34.5	1.5	42	22
20491-18-06TRW	--	M18X1.5	10	06	12	O10.0X1.5	36.3	1.5	44.3	22
20491-18-08WRW	20492-18-08WRW	M18X1.5	12	08	12	O10.0X1.5	42.5	1.8	53.7	22
20491-22-05TRW	--	M22X1.5	8	05	15	O12.0X2.0	34.5	3	42.5	27
20491-22-06TRW	--	M22X1.5	10	06	15	O12.0X2.0	36.3	3	44.8	27
20491-22-08TRW	20492-22-08TRW	M22X1.5	12	08	15	O12.0X2.0	42.5	3	50	27
20491-22-10WRW	20492-22-10WRW	M22X1.5	16	10	15	O12.0X2.0	57	3	58.6	27
20491-26-08TRW	20492-26-08TRW	M26X1.5	12	08	18	O15.0X2.0	42.5	2.1	50.9	32
20491-26-10TRW	20492-26-10TRW	M26X1.5	16	10	18	O15.0X2.0	57	2.1	55.4	32
20491-26-12WRW	20492-26-12WRW	M26X1.5	20	12	18	O15.0X2.0	63.2	2.1	65.9	32
20491-30-10TRW	20492-30-10TRW	M30X2	16	10	22	O20.0X2.0	57	3.8	58.2	36
20491-30-12TRW	20492-30-12TRW	M30X2	20	12	22	O20.0X2.0	63.2	3.8	64.7	36
20491-30-16WRW	20492-30-16WRW	M30X2	25	16	22	O20.0X2.0	78.9	3.8	77.3	36
20491-36-12TRW	20492-36-12TRW	M36X2	20	12	28	O26.0X2.0	63.2	4.5	64	41
20491-36-16TRW	20492-36-16TRW	M36X2	25	16	28	O26.0X2.0	78.9	4.5	72.5	41
20491-36-20WRW	20492-36-20WRW	M36X2	32	20	28	O26.0X2.0	92.7	4.5	88.6	41
20491-45-16TRW	20492-45-16TRW	M45X2	25	16	35	O32.0X2.5	78.9	4	75.5	50
20491-45-20TRW	20492-45-20TRW	M45X2	32	20	35	O32.0X2.5	92.7	4	86.5	50
20491-52-20TRW	20492-52-20TRW	M52X2	32	20	42	O38.0X2.5	92.7	4	87.5	60
20491-52-24TRW	20492-52-24TRW	M52X2	40	24	42	O38.0X2.5	111.4	4	101	60

代号	螺纹E	软管		尺寸
代号	螺纹E	公称内径	标号	A	C	H	S2
20791-12-04C	M12X1.25	6	04	30	9	33.5	17
20791-12-04	M12X1.5	6	04	30	10	33.5	17
20791-14-04	M14X1.5	6	04	27.5	8.5	34	19
20791-16-04	M16X1.5	6	04	30	8	35	22
20791-16-05	M16X1.5	8	05	31	8	39.5	22
20791-18-06	M18X1.5	10	06	33	10	42	24
20791-22-08	M22X1.5	12	08	42.5	10	49.5	27
20791-22-10	M22X1.5	16	10	56	10	52.5	27
20791-27-10	M27X1.5	16	10	48.5	11	54.5	32
20791-30-12	M30X1.5	20	12	50.5	11	63.5	36
20791-33-12	M33X1.5	20	12	65.5	13	63.5	41
20791-33-16	M33X1.5	25	16	66	13	75.5	41
20791-36-12	M36X2	20	12	65.5	124	63.5	41
20791-36-14	M36X2	22	14	71.2	14	64.5	41
20791-39-16	M39X2	25	16	66	14	76.5	46
20791-45-20W	M45X2	32	20	91.5	15	83	55
20791-52-21W	M52X2	32	20	93	17	84.5	60
20791-52-24W	M52X1.5	40	24	110.7	17	96.5	60
注：1.上诉代号用于编制软管。 2.如需用于缠绕软管代码号改为20792-xx-xx。 NOTE : 1.FOR USE WITH BRAIDED HOSES 2.IF USE WITH SPIRAL HOSES ,HOSE FITTINGS SERIES NUMBER IS 20792-XX-XX.

代号 PART NO.		螺纹E	胶管 HOSE BORE		管子外径	尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	TUBE O.D.	A	C	S1
10411-12-04RW	--	M12X1.5	6	04	6	20	10	12
10411-14-04RW	--	M14X1.5	6	04	8	21	10	14
10411-14-05RW	--	M14X1.5	8	05	8	21	10	14
10411-16-04RW	--	M16X1.5	6	04	10	22	11	17
10411-16-05RW	--	M16X1.5	8	04	10	22	11	17
10411-16-06RW	--	M16X1.5	10	06	10	21.5	11	17
10411-18-05RW	--	M18X1.5	8	05	12	23	11	19
10411-18-06RW	--	M18X1.5	10	06	12	22.5	11	19
10411-22-06RW	--	M22X1.5	10	06	15	23.5	12	24
10411-22-08RW	10412-22-08RW	M22X1.5	12	08	15	24.5	12	24
10411-26-08RW	10412-26-08RW	M26X1.5	12	08	18	25.5	12	27
10411-26-10RW	10412-26-10RW	M26X1.5	16	10	18	26	12	27
10411-30-10RW	10412-30-10RW	M30X2	16	10	22	28	14	32
10411-30-12RW	10412-30-12RW	M30X2	20	12	22	27	14	32
10411-36-16RW	10412-36-16RW	M36X2	25	16	28	31.2	14	38
10411-45-20RW	10412-45-20RW	M45X2	32	20	35	34.2	16	46
10411-52-24RW	10412-52-24RW	M52X2	40	24	42	37	16	55

代号 PART NO.		胶管 HOSE BORE		管子外径	尺寸 DIMENSIONS			备注
编织 BRAIDED	缠绕 SPIRAL	公称内径 DN	标号DASH	TUBE O.D.	A	C	H	NOTE
50041-06-04RW	--	6	04	6	53.7	22	30.1	轻系列
50041-08-05RW	--	8	05	8	57.2	24	32.4
50041-08-06RW	--	10	06	8	58.9	24	33.1
50041-10-05RW	--	8	05	10	55.5	23	30.6
50041-10-06RW	--	10	06	10	57.1	23	31.3
50041-12-06RW	--	10	06	12	59.5	23	34.5
50041-12-08RW	50042-12-08RW	12	008	12	72.9	23	37.4
50041-15-06RW	50042-15-06RW	10	06	15	60.3	25	34.5
50041-15-08RW	50042-15-08RW	12	08	15	71.1	25	35.7
50041-18-08RW	50042-18-08RW	12	08	18	73.9	26	38.5
50041-18-10RW	50042-18-10RW	16	10	18	86.1	26	39.8
50041-22-10RW	50042-22-10RW	16	10	22	88.6	28	42.3
50041-22-12RW	50042-22-12RW	20	12	22	93.3	28	45.9
50041-22-16RW	50042-22-16RW	25	16	22	103.1	28	46.7
50041-28-16RW	50042-28-16RW	25	16	28	105.9	30	49.5
50041-35-20RW	50042-35-20RW	32	20	35	119.7	36	57.8
50041-42-24RW	50042-42-24RW	40	24	42	112.3	40	59.6
50041-08-04RW	--	6	04	8	55.1	24	31.5	重系列
50041-08-05RW	--	8	05	8	57.2	24	32.4
50041-08-06RW	--	10	06	8	58.9	24	33.1
50041-10-04RW	--	6	04	10	55.5	26	31.9
50041-12-04RW	--	6	04	12	58.6	26	35.1
50041-12-05RW	--	8	05	12	60.7	26	35.9
50041-14-06RW	--	10	06	14	62.6	29	37.3
50041-14-08RW	50042-14-08RW	12	08	14	74.3	29	38.8
50041-14-12RW	50042-14-12RW	20	12	14	91.9	29	43.8
50041-16-08RW	50042-16-08RW	12	08	16	77.1	30	41.7
50041-16-10RW	50042-16-10RW	16	10	16	89.3	30	43
50041-20-10RW	50042-20-10RW	16	10	20	94.3	36	48
50041-20-12RW	50042-20-12RW	20	12	20	100.7	36	52.6
50041-25-12RW	50042-25-12RW	20	12	25	101.8	40	54.4
50041-25-16RW	50042-25-16RW	25	16	25	111.6	40	55.2
50041-30-16RW	50042-30-16RW	25	16	30	115.8	44	59.4
50041-30-20RW	50042-30-20RW	32	20	30	125.4	44	63.5
50041-38-16RW	50042-38-16RW	25	16	38	120.1	50	63.6
50041-38-20RW	50042-38-20RW	32	20	38	129.6	50	67.7

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	A	C	S1
12611A-02-04RW	--	G1/8”X28	6	04	22	10	14
12611A-04-04RW	--	G1/4”X28	6	04	24	12	19
12611A-04-05RW	--	G1/4”X28	8	05	24	12	19
12611A-04-06RW	--	G1/4”X28	10	06	23.5	12	19
12611A-06-04RW	--	G3/8”X19	6	04	27.5	13.5	22
12611A-06-05RW	--	G3/8”X19	8	05	27.5	13.5	22
12611A-06-06RW	--	G3/8”X19	10	06	27	13.5	22
12611A-06-08RW	12612A-06-08RW	G3/8”X19	12	08	28	13.5	22
12611A-08-06RW	--	G1/2”X14	10	06	31.5	16	27
12611A-08-08RW	12612A-08-08RW	G1/2”X14	12	08	32.5	16	27
12611A-08-10RW	12612A-08-10RW	G1/2”X14	10	06	31.5	16	27
12611A-08-12RW	12612A-08-12RW	G1/2”X14	20	12	32	16	27
12611A-12-08RW	12612A-12-08RW	G3/4”X14	12	08	36	18.5	32
12611A-12-10RW	12612A-12-10RW	G3/4”X14	16	10	36.5	18.5	32
12611A-12-12RW	12612A-12-12RW	G3/4”X14	20	12	35.5	18.5	32
12611A-12-16RW	12612A-12-16RW	G3/4”X14	25	16	38.7	18.5	32
12611A-16-12RW	12612A-16-12RW	G1”X11	20	12	39.5	20.5	41
12611A-16-16RW	12612A-16-16RW	G1”X11	25	16	42.7	20.5	41
12611A-20-20RW	12612A-20-20RW	G1.1/4”X11	32	20	44.7	20.5	50
12611A-24-24RW	12612A-24-24RW	G1.1/2”X11	40	24	48	23	55
12611A-32-24RW	12612A-32-24RW	G2”X11	40	24	52.5	25.5	70
12611A-32-32RW	12612A-32-32RW	G2”X11	50	32	56	25.5	70

代号 PART NO.		螺纹E	胶管 HOSE BORE		O形圈	尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	O RING	A	C	S1
12211-04-04RW	--	G1/4”X19	6	04	O111	23	11	19
12211-04-06RW	--	G1/4”X19	10	06	O111	22.5	11	19
12211-06-06RW	--	G3/8”X19	10	06	O113	25.5	12	22
12211-08-04RW	--	G1/2”X14	6	04	O115	30	14	27
12211-08-06RW	--	G1/2”X14	10	06	O115	29.5	14	27
12211-08-08RW	12212-08-08RW	G1/2”X14	12	08	O115	30.5	14	27
12211-10-10RW	12212-10-10RW	G5/8”X14	16	10	O910	32.5	15.5	30
12211-12-10RW	12212-12-10RW	G3/4”X14	16	10	O119	33.5	15.5	32
12211-12-12RW	12212-12-12RW	G3/4”X14	20	12	O119	32.5	15.5	32
12211-12-16RW	12212-12-16RW	G3/4”X14	25	16	O119	35.7	15.5	32
12211-16-16RW	12212-16-16RW	G1”X11	25	16	O217	40.7	18.5	41
12211-20-20RW	12212-20-20RW	G1.1/4”X11	32	20	O222	44.2	20	50

代号	螺纹E	软管		尺寸
代号	螺纹E	公称内径	标号	A	C	S1
13011-02-03SP	R1/8”X28	5	03	22	10	12
13011-02-04SP	R1/8”X28	6	04	22.5	10	12
13011-04-04SP	R1/4”X19	6	04	27	14.5	14
13011-04-05SP	R1/4”X19	8	05	25	15.4	14
13011-04-06SP	R1/4”X19	10	06	27	14.5	17
13011-06-04SP	R3/8”X19	6	04	27.5	15	17
13011-06-05SP	R3/8”X19	8	05	26.5	15	17
13011-06-06SP	R3/8”X19	10	06	27.5	15	17
13011-06-08SP	R3/8”X19	12	08	30	15	19
13011-08-06SP	R1/2”X14	10	06	34.5	20	22
13011-08-08SP	R1/2”X14	12	08	35	20	22
13011-08-10SP	R1/2”X14	16	10	38	20	22
13011-08-12SP	R1/2”X14	20	12	38	20	27
13011-12-08SP	R3/4”X14	12	08	37	20	27
13011-12-10SP	R3/4”X14	16	10	38	20	27
13011-12-12SP	R3/4”X14	20	12	38.5	20	27
13011-12-16SP	R3/4”X14	25	16	39.5	20	32
13011-16-12SP	R1”X11	20	12	44	25.5	36
13011-16-16SP	R1”X11	25	16	45	25.5	36
13011-20-20SP	R1.1/4”X11	32	20	49.5	26.5	46
13011-24-24SP	R1.1/2”X11	40	24	52.5	26.5	50
13011-32-24SP	R2”X11	40	24	57	30	65
13011-32-32SP	R2”X11	50	32	59	30	65
注：1.上诉代号用于编制软管。 2.如需用于缠绕软管代码号改为13012-xx-xx。 NOTE : 1.FOR USE WITH BRAIDED HOSES 2.IF USE WITH SPIRAL HOSES ,HOSE FITTINGS SERIES NUMBER IS 13012-XX-XX.

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	A	C	S2
22111-02-04RW	--	G1/8”X28	6	04	21	2	14
22111-04-04RW	--	G1/4”X19	6	04	21	4	19
22111-06-05RW	--	G3/8”X19	8	05	22	5	22
22111-06-06RW	--	G3/8”X19	10	06	22	5	22
22111-06-08RW	22112-06-08RW	G3/8”X19	12	08	23	5	22
22111-08-04TRW	--	G1/2”X14	6	04	21	6	27
22111-08-06TRW	--	G1/2”X14	10	06	20.5	6	27
22111-08-08RW	22112-08-08RW	G1/2”X14	12	08	25	6	27
22111-08-10RW	22112-08-10RW	G1/2”X14	16	10	25.5	6	27
22111-10-10RW	22112-10-10RW	G5/8”X14	16	10	26	8	30
22111-10-12RW	22112-10-12RW	G5/8”X14	20	12	25.5	8	30
22111-12-08TRW	22112-12-08TRW	G3/4”X14	12	08	23	9.5	32
22111-12-10TRW	22112-12-10TRW	G3/4”X14	16	10	23.5	9.5	32
22111-12-12RW	22112-12-12RW	G3/4”X14	20	12	26.5	9.5	32
22111-16-12TRW	22112-16-12TRW	G1”X11	20	12	22.5	11	41
22111-16-16RW	22112-16-16RW	G1”X11	25	16	30.2	11	41
22111-20-16TRW	22112-20-16TRW	G1.1/4”X11	25	16	28.7	11	50
22111-20-20RW	22112-20-20RW	G1.1/4”X11	32	20	30.7	10	50
22111-24-24RW	22112-20-21RW	G1.1/2”X11	40	24	39	11.5	55
22111-32-32RW	22112-32-32RW	G2”X11	50	32	43.5	15	70

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	A	C	H	S2
22641-04-04RW	--	G1/4”X19	6	04	43.8	5.5	20.2	19
22641-04-05RW	--	G1/4”X19	8	05	45.9	5.5	21.1	19
22641-04-06RW	--	G1/4”X19	10	06	47	5.5	21.8	19
22641-06-04TRW	--	G3/8”X19	6	04	43.2	6.3	19.6	22
22641-06-05TRW	--	G3/8”X19	8	05	45.3	6.3	20.5	22
22641-06-06RW	--	G3/8”X19	10	06	47.8	6.3	22.6	22
22641-06-08RW	--	G3/8”X19	12	08	61.2	6.3	24.8	22
22641-08-06TRW	--	G1/2”X14	10	06	47.7	7.5	22.5	27
22641-08-08RW	22642-08-08RW	G1/2”X14	12	08	62.5	7.5	26.1	27
22641-10-08TRW	22642-10-08TRW	G5/8”X14	12	08	60.8	9.5	24.4	30
22641-10-10RW	22642-10-10RW	G5/8”X14	10	10	73.1	9.5	27.8	30
22641-12-08TRW	22642-12-08TRW	G3/4”X14	12	08	61.2	10.9	24.8	32
22641-12-10TRW	22642-12-10TRW	G3/4”X14	16	10	71.4	10.9	26.1	32
22641-12-12RW	22642-12-12RW	G3/4”X14	20	12	76.8	10.9	31	32
22641-16-12TRW	22642-16-12TRW	G1”X11	20	12	75.5	11.7	29.7	41
22641-16-16RW	22642-16-16RW	G1”X11	25	16	90.6	11.7	34.2	41
22641-20-16TRW	22642-20-16TRW	G1.1/4”X11	25	16	88.6	11	32.2	50
22641-20-20WRW	22642-20-20WRW	G1.1/4”X11	32	20	103.1	11	41.2	50
22641-24-20TRW	22642-24-20TRW	G1.1/2”X11	32	20	99.2	13	37.3	55
22641-24-24WRW	22642-24-24WRW	G1.1/2”X11	40	24	118.5	13	45.8	55
22641-32-24TRW	22642-32-24TRW	G2”X11	40	24	116.4	16	43.7	70
22641-32-32WRW	22642-32-32WRW	G2”X11	50	32	142.8	16	53	70

代号	螺纹E	软管		尺寸
代号	螺纹E	公称内径	标号	A	C	H	S2
22191-02-04	G1/8”X28	6	04	30	2	38	14
22191-04-03	G1/4”X19	5	03	27	4	35	19
22191-04-04	G1/4”X19	6	04	30	4	38	19
22191-04-05	G1/4”X19	8	05	33	4	41.5	19
22191-06-05	G3/8”X19	8	05	33	5	42	22
22191-06-06	G3/8”X19	10	06	35.3	5	44.3	22
22191-06-08	G3/8”X19	12	08	41	5	50	22
22191-08-06T	G1/2”X14	10	06	35.3	6	46.8	27
22191-08-08	G1/2”X14	12	08	41	6	52.5	27
22191-10-10	G5/8”X14	16	10	56.5	8	57.5	30
22191-10-12	G5/8”X14	20	12	65.5	8	67	30
22191-12-08T	G3/4”X14	12	08	41	9.5	52	32
22191-12-10	G3/4”X14	16	10	56.5	9.5	58.5	32
22191-12-12	G3/4”X14	20	12	65.5	9.5	68	32
22191-16-12T	G1”X11	20	12	66.2	11	68.5	41
22191-16-14	G1”X11	22	14	71.2	11	69.5	41
22191-16-16	G1”X11	25	16	76.7	11	75	41
22191-20-16T	G1.1/4”X11	25	16	76.7	10	78	50
22191-20-20W	G1.1/4”X11	32	20	92.3	10	85.3	50
22191-24-24W	G1.1/2”X11	40	24	109.4	11.5	108	55
22191-32-32W	G2”X11	50	32	133.1	15	123.8	70
注：1.上诉代号用于编制软管。 2.如需用于缠绕软管代码号改为22192-xx-xx。 NOTE : 1.FOR USE WITH BRAIDED HOSES 2.IF USE WITH SPIRAL HOSES ,HOSE FITTINGS SERIES NUMBER IS 22192-XX-XX.

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	A	C	S1
22611-04-04RW	--	G1/4”X19	6	04	19.5	5.5	19
22611-04-05RW	--	G1/4”X19	8	05	19.5	5.5	19
22611-04-06RW	--	G1/4”X19	10	06	19.5	5.5	19
22611-06-04TRW	--	G3/8”X19	6	04	18.2	6.3	22
22611-06-05TRW	--	G3/8”X19	8	05	18.2	6.3	22
22611-06-06RW	--	G3/8”X19	10	06	20.7	6.3	22
22611-06-08RW	--	G3/8”X19	12	08	21.7	6.3	22
22611-08-06TRW	--	G1/2”X14	10	06	19.5	7.5	27
22611-08-08RW	22612-08-08RW	G1/2”X14	12	08	23.5	7.5	27
22611-10-08TRW	22612-10-08TRW	G5/8”X14	12	08	21	9.5	30
22611-10-10RW	22612-10-10RW	G5/8”X14	10	10	24.5	9.5	30
22611-12-08TRW	22612-12-08TRW	G3/4”X14	12	08	21.6	10.9	32
22611-12-10TRW	22612-12-10TRW	G3/4”X14	16	10	22.1	10.9	32
22611-12-12RW	22612-12-12RW	G3/4”X14	20	12	24.6	10.9	32
22611-16-12TRW	22612-16-12TRW	G1”X11	20	12	22.3	11.7	41
22611-16-16RW	22612-16-16RW	G1”X11	25	16	29	11.7	41
22611-20-16TRW	22612-20-16TRW	G1.1/4”X11	25	16	26.8	11	50
22611-20-20WRW	22612-20-20WRW	G1.1/4”X11	32	20	29.7	11	50
22611-24-20TRW	22612-24-20TRW	G1.1/2”X11	32	20	28.8	13	55
22611-24-24WRW	22612-24-24WRW	G1.1/2”X11	40	24	34.5	13	55
22611-32-24TRW	22612-32-24TRW	G2”X11	40	24	32.5	16	70
22611-32-32WRW	22612-32-32WRW	G2”X11	50	32	38	16	70

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	A	C	S1
13011-02-04SPRW	--	R1/8”X28	6	04	22	10	12
13011-04-04SPRW	--	R1/4”X28	6	04	26.5	14.5	14
13011-04-05SPRW	--	R1/4”X28	8	05	27.4	15.4	14
13011-04-06SPRW	--	R1/4”X28	10	06	26	14.5	17
13011-06-04SPRW	--	R3/8”X19	6	04	27	15	17
13011-06-05SPRW	--	R3/8”X19	8	05	27	15	17
13011-06-06SPRW	--	R3/8”X19	10	06	26.5	15	17
13011-06-08SPRW	13012-06-08SPRW	R3/8”X19	12	08	27.5	15	19
13011-08-06SPRW	--	R1/2”X14	10	06	33.5	20	22
13011-08-08SPRW	13012-08-08SPRW	R1/2”X14	12	08	34.5	20	22
13011-08-10SPRW	13012-08-10SPRW	R1/2”X14	10	06	33.5	20	22
13011-08-12SPRW	13012-08-12SPRW	R1/2”X14	20	12	36	20	27
13011-12-08SPRW	13012-12-08SPRW	R3/4”X14	12	08	36.5	20	27
13011-12-10SPRW	13012-12-10SPRW	R3/4”X14	16	10	37	20	27
13011-12-12SPRW	13012-12-12SPRW	R3/4”X14	20	12	36	20	27
13011-12-16SPRW	13012-12-16SPRW	R3/4”X14	25	16	40.2	20	32
13011-16-12SPRW	13012-16-12SPRW	R1”X11	20	12	42.5	25.5	36
13011-16-16SPRW	13012-16-16SPRW	R1”X11	25	16	45.7	25.5	36
13011-20-20SPRW	13012-20-20SPRW	R1.1/4”X11	32	20	48.7	26.5	46
13011-24-24SPRW	13012-24-24SPRW	R1.1/2”X11	40	24	51.5	26.5	50
13011-32-24SPRW	13012-32-24SPRW	R2”X11	40	24	57	30	65
13011-32-32SPRW	13012-32-32SPRW	R2”X11	50	32	60.5	30	65

代号	管子外径D	软管		尺寸
代号	管子外径D	公称内径	标号	A	C	H	S2
22691-02-03	G1/8”X28	5	03	26.5	5.5	31.5	14
22691-02-04	G1/8”X28	6	04	27.5	5.5	35.5	14
22691-04-03	G1/4”X19	5	03	26.5	5.5	33.5	19
22691-04-04	G1/4”X19	6	04	27.5	5.5	37	19
22691-04-05	G1/4”X19	8	05	31	5.5	41.5	19
22691-04-06	G1/4”X19	10	06	30	5.5	36.5	19
22691-06-04	G3/8”X19	6	04	27.5	6.3	39	22
22691-06-05	G3/8”X19	8	05	31	6.3	43.5	22
22691-06-06	G3/8”X19	10	06	33	6.3	44.5	22
22691-08-06T	G1/2”X14	10	06	35.3	7	43.3	27
22691-08-08	G1/2”X14	12	08	42.5	7.5	53	27
22691-08-10	G1/2”X14	16	10	56.5	7.5	55.5	27
22691-10-08	G5/8”X14	12	08	42.5	9.5	53.5	30
22691-10-10	G5/8”X14	16	10	48.5	9.5	58	30
22691-12-08T	G3/4”X14	12	08	41	10.9	52.1	32
22691-12-10	G3/4”X14	16	10	48.5	10.9	58	32
22691-12-12	G3/4”X14	20	12	50.5	10.9	66	32
22691-16-12T	G1”X11	20	12	65.5	11.7	68.3	41
22691-16-14	G1”X11	22	14	71.2	11.7	69.3	41
22691-16-16	G1”X11	25	16	66	11.7	78.5	41
22691-20-16T	G1.1/4”X11	25	16	78	11	69.5	50
22691-20-20W	G1.1/4”X11	32	20	91.5	11	84.3	50
22691-24-24W	G1.1/2”X11	40	24	109.4	13	103	55
22691-32-32W	G2”X11	50	32	131.8	16	123.3	70
注：1.上诉代号用于编制软管。 2.如需用于缠绕软管代码号改为22692-xx-xx。 NOTE : 1.FOR USE WITH BRAIDED HOSES 2.IF USE WITH SPIRAL HOSES ,HOSE FITTINGS SERIES NUMBER IS 22692-XX-XX.

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	A	C	H	S2
22141-02-04RW	--	G1/8”X28	6	04	44.9	2	21.3	14
22141-04-04RW	--	G1/4”X19	6	04	44.9	4	21.3	19
22141-06-05RW	--	G3/8”X19	8	05	47.7	5	22.9	22
22141-06-06RW	--	G3/8”X19	10	06	48.8	5	23.6	22
22141-06-08RW	22142-06-08RW	G3/8”X19	12	08	62.2	5	25.8	22
22141-08-04TRW	--	G1/2”X14	6	04	45.2	6	21.6	27
22141-08-06TRW	--	G1/2”X14	10	06	48.4	6	23.2	27
22141-08-08RW	22142-08-08RW	G1/2”X14	12	08	63.6	6	27.2	27
22141-08-10RW	22142-08-10RW	G1/2”X14	16	10	73.8	6	28.5	27
22141-10-10RW	22142-10-10RW	G5/8”X14	16	10	74.1	8	28.8	30
22141-10-12RW	22142-10-12RW	G5/8”X14	20	12	77.4	8	31.6	30
22141-12-08TRW	22142-12-08TRW	G3/4”X14	12	08	62.2	9.5	25.8	32
22141-12-10TRW	22142-12-10TRW	G3/4”X14	16	10	72.4	9.5	27.1	32
22141-12-12RW	22142-12-12RW	G3/4”X14	20	12	78.1	9.5	32.3	32
22141-16-12TRW	22142-16-12TRW	G1”X11	20	12	75.7	11	29.9	41
22141-16-16RW	22142-16-16RW	G1”X11	25	16	91.4	11	35	41
22141-20-16TRW	22142-20-16TRW	G1.1/4”X11	25	16	90	11	33.6	50
22141-20-20WRW	22142-20-20RW	G1.1/4”X11	32	20	101	10	41.9	50
22141-24-24WRW	22142-20-21RW	G1.1/2”X11	40	24	121.7	11.5	49	55
22141-32-32WRW	22142-32-32RW	G2”X11	50	32	146.7	15	56.9	70

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	A	C	H	S2
22691-04-04RW	--	G1/4”X19	6	04	31.5	5.5	36.5	19
22691-04-05RW	--	G1/4”X19	8	05	34.5	5.5	39.5	19
22691-04-06RW	--	G1/4”X19	10	06	36.3	5.5	41.8	19
22691-06-04TRW	--	G3/8”X19	6	04	31.5	6.3	35.7	22
22691-06-05TRW	--	G3/8”X19	8	05	34.5	6.3	40.7	22
22691-06-06RW	--	G3/8”X19	10	06	36.3	6.3	43	22
22691-06-08RW	--	G3/8”X19	12	08	42.5	6.3	49.2	22
22691-08-06TRW	--	G1/2”X14	10	06	36.3	7.5	42.8	27
22691-08-08RW	22692-08-08RW	G1/2”X14	12	08	42.5	7.5	51	27
22691-10-08TRW	22692-10-08TRW	G5/8”X14	12	08	42.5	9.5	48.5	30
22691-10-10RW	22692-10-10RW	G5/8”X14	10	10	57	9.5	56	30
22691-12-08TRW	22692-12-08TRW	G3/4”X14	12	08	42.5	10.9	49.1	32
22691-12-10TRW	22692-12-10TRW	G3/4”X14	16	10	57	10.9	53.6	32
22691-12-12RW	22692-12-12RW	G3/4”X14	20	12	63.2	10.9	63.1	32
22691-16-12TRW	22692-16-12TRW	G1”X11	20	12	63.2	11.7	61.3	41
22691-16-16RW	22692-16-16RW	G1”X11	25	16	78.9	11.7	73.8	41
22691-20-16TRW	22692-20-16TRW	G1.1/4”X11	25	16	78.9	11	71.1	50
22691-20-20WRW	22692-20-20WRW	G1.1/4”X11	32	20	92.7	11	89	50
22691-24-20TRW	22692-24-20TRW	G1.1/2”X11	32	20	92.7	13	83.5	55
22691-24-24WRW	22692-24-24WRW	G1.1/2”X11	40	24	111.4	13	103.5	55
22691-32-24TRW	22692-32-24TRW	G2”X11	40	24	111.4	16	100.5	70
22691-32-32WRW	22692-32-32WRW	G2”X11	50	32	138.6	16	123.8	70

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	A	C	S1
10711-14-04RW	--	M14X1.5	6	04	30	18	17
10711-14-06RW	--	M14X1.5	10	06	29.5	18	17
10711-16-05RW	--	M16X1.5	8	05	31	19	17
10711-16-05RW	--	M16X1.5	8	05	31	19	17
10711-18-06RW	--	M18X1.5	10	06	30.5	19	19
10711-22-08RW	--	M22X1.5	12	08	34	19.5	22
10711-24-08RW	10712-24-08RW	M24X1.5	12	08	34.5	20	24
10711-27-10RW	10712-27-10RW	M27X1.5	16	10	37.5	20.5	27
10711-30-12RW	10712-30-12RW	M30X1.5	20	12	40	23	32
10711-33-12RW	10712-33-12RW	M33X2	20	12	43	26	36
10711-39-16RW	10712-39-16RW	M39X2	25	16	49.7	27.5	41
10711-42-20RW	10712-42-20RW	M42X2	32	20	50.7	28.5	46
10711-45-20RW	10712-45-20RW	M45X2	32	20	50.7	28.5	46

代号	螺纹E	软管		管子外径	O形圈	尺寸
代号	螺纹E	公称内径	标号	管子外径	O形圈	A	C	S2
20411-12-04	M12X1.5	6	04	6	O04.5X1.5	25	1	17
20411-14-04	M14X1.5	6	04	8	O06.5X1.5	26.5	2	19
20411-14-06	M14X1.5	10	06	8	O06.5X1.5	27.5	2	19
20411-16-04	M16X1.5	6	04	10	O08.0X1.5	27	2	22
20411-16-05	M16X1.5	8	05	10	O08.0X1.5	27	2	22
20411-16-06	M16X1.5	10	06	10	O08.0X1.5	28	2	22
20411-18-05T	M18X1.5	8	05	12	O10.0X1.5	25.5	1.5	22
20411-18-06	M18X1.5	10	06	12	O10.0X1.5	29	2.5	24
20411-18-08	M18X1.5	12	08	12	O10.0X1.5	29.5	2.5	24
20411-22-05T	M22X1.5	8	05	15	O12.0X2	26.5	3	27
20411-22-06T	M22X1.5	10	06	15	O12.0X2	28.5	3	27
20411-22-08	M22X1.5	12	08	15	O12.0X2	32.5	2.5	27
20411-26-10	M26X1.5	16	10	18	O15.0X2	34.5	2.5	32
20411-26-12	M26X1.5	20	12	18	O15.0X2	34.5	2.5	32
20411-30-10T	M30X2	16	10	22	O20.0X2	33	3.8	36
20411-30-12	M30X2	20	12	22	O20.0X2	36.5	4	36
20411-36-12T	M36X2	20	12	28	O26.0X2	36	4.5	46
20411-36-14T	M36X2	22	14	28	O26.0X2	36.5	4.5	46
20411-45-16T	M45X2	25	16	35	O32.0X2	42	4	55
20411-45-20T	M45X2	32	20	35	O32.0X2	43	4	55
20411-52-20T	M52X2	32	20	42	O38.0X2	44.5	4	60
20411-52-24T	M52X2	40	24	42	O38.0X2	44.5	4	60
注：1.上诉代号用于编制软管。 2.如需用于缠绕软管代码号改为20412-xx-xx。 NOTE : 1.FOR USE WITH BRAIDED HOSES 2.IF USE WITH SPIRAL HOSES ,HOSE FITTINGS SERIES NUMBER IS 20412-XX-XX.

代号	螺纹E	软管		管子外径	尺寸
代号	螺纹E	公称内径	标号	管子外径	A	C	S1
10511-14-04	M14X1.5	6	04	6	24	12	14
10511-16-04	M16X1.5	6	04	8	24.5	12	17
10511-18-04	M18X1.5	6	04	10	25	12	19
10511-20-05	M20X1.5	8	05	12	26	12	22
10511-20-06	M20X1.5	10	06	12	26	12	22
10511-22-05	M22X1.5	8	05	14	28.5	14	24
10511-22-06	M22X1.5	10	06	14	28.5	14	24
10511-22-08	M22X1.5	12	08	14	29	14	24
10511-24-08	M24X1.5	12	08	16	30	14	27
10511-30-10	M30X2	16	10	20	35.5	16	32
10511-30-12	M30X2	20	12	20	35.5	16	32
10511-36-12	M36X2	20	12	25	38.5	18	38
10511-36-16	M36X2	25	16	25	40	18	38
10511-42-16	M42X2	25	16	30	43	20	46
10511-42-20	M42X2	32	20	30	44	20	46
10511-52-20	M52X2	32	20	38	48	22	55
注：1.上诉代号用于编制软管。 2.如需用于缠绕软管代码号改为10512-xx-xx。 NOTE : 1.FOR USE WITH BRAIDED HOSES 2.IF USE WITH SPIRAL HOSES ,HOSE FITTINGS SERIES NUMBER IS 10512-XX-XX.

代号	螺纹E	软管		尺寸
代号	螺纹E	公称内径	标号	A	C	H	S2
20741-14-04	M14X1.5	6	04	38	8.5	19	19
20741-16-05	M16X1.5	8	05	42.3	8	20.7	22
20741-18-06	M18X1.5	10	06	45.5	10	22	24
20741-22-08	M22X1.5	12	08	57.5	10	24.5	27
20741-27-10	M27X1.5	16	10	60	11	26.5	32
20741-30-12	M30X1.5	20	12	74	11	30	36
20741-33-12	M33X2	20	12	77.4	13	30	41
20741-33-16	M33X2	25	16	85	13	30.8	41
20741-36-14	M36X2	22	14	79.8	14	29.6	4
20741-36-16	M36X2	25	16	85.7	14	31.5	41
20741-39-16	M39X2	25	16	85	14	33	46
20741-45-20W	M45X2	32	20	97	15	36.2	55
20741-52-24W	M52X2	40	24	115.3	17	40.6	60
注：1.上诉代号用于编制软管。 2.如需用于缠绕软管代码号改为20742-xx-xx。 NOTE : 1.FOR USE WITH BRAIDED HOSES 2.IF USE WITH SPIRAL HOSES ,HOSE FITTINGS SERIES NUMBER IS 20742-XX-XX.

代号	管子外径D	软管		尺寸
代号	管子外径D	公称内径	标号	A	C	S2
22611-02-03	G1/8”X28	5	03	15	5.5	14
22611-02-04	G1/8”X28	6	04	17.5	5.5	14
22611-04-03	G1/4”X19	5	03	17	5.5	19
22611-04-04	G1/4”X19	6	04	19	5.5	19
22611-04-05	G1/4”X19	8	05	19	5.5	19
22611-04-06	G1/4”X19	10	06	19	5.5	19
22611-06-04	G3/8”X19	6	04	21	6.3	22
22611-06-05	G3/8”X19	8	05	21	6.3	22
22611-06-06	G3/8”X19	10	06	21	6.3	22
22611-06-08	G3/8”X19	12	08	21.5	6.3	22
22611-08-06T	G1/2”X14	10	06	21	7.5	27
22611-08-08	G1/2”X14	12	08	23	7.5	27
22611-10-08	G5/8”X14	12	08	23.5	9.5	30
22611-10-10	G5/8”X14	16	10	24.5	9.5	30
22611-12-08T	G3/4”X14	12	08	22	10.9	32
22611-12-10	G3/4”X14	16	10	24.5	10.9	32
22611-12-12	G3/4”X14	20	12	24.5	10.9	32
22611-16-12T	G1”X11	20	12	24	11.7	41
22611-16-14	G1”X11	22	14	26	11.7	41
22611-16-16	G1”X11	25	16	27.5	11.7	41
22611-20-16T	G1.1/4”X11	25	16	27.5	11	50
22611-20-20W	G1.1/4”X11	32	20	30.5	11	50
22611-24-20T	G1.1/2”X11	32	20	32	13	55
22611-24-24W	G1.1/2”X11	40	24	32	13	55
22611-32-24T	G2”X11	40	24	30	16	70
22611-32-32W	G2”X11	50	32	31.9	16	70
注：1.上诉代号用于编制软管。 2.如需用于缠绕软管代码号改为22612-xx-xx。 NOTE : 1.FOR USE WITH BRAIDED HOSES 2.IF USE WITH SPIRAL HOSES ,HOSE FITTINGS SERIES NUMBER IS 22612-XX-XX.

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	A	C	H	S2
22191-02-04RW	--	G1/8”X28	6	04	31.5	2	38	14
22191-04-04RW	--	G1/4”X19	6	04	31.5	4	38	19
22191-06-05RW	--	G3/8”X19	8	05	34.5	5	42	22
22191-06-06RW	--	G3/8”X19	10	06	36.3	5	44.3	22
22191-06-08RW	22192-06-08RW	G3/8”X19	12	08	42.5	5	50.5	22
22191-08-04TRW	--	G1/2”X14	6	04	31.5	6	38.5	27
22191-08-06TRW	--	G1/2”X14	10	06	36.3	6	43.8	27
22191-08-08RW	22192-08-08RW	G1/2”X14	12	08	42.5	6	52.5	27
22191-08-10RW	22192-08-10RW	G1/2”X14	16	10	57	6	57	27
22191-10-10RW	22192-10-10RW	G5/8”X14	16	10	57	8	57.5	30
22191-10-12RW	22192-10-12RW	G5/8”X14	20	12	63.2	8	64	30
22191-12-08TRW	22192-12-08TRW	G3/4”X14	12	08	42.5	9.5	50.5	32
22191-12-10TRW	22192-12-10TRW	G3/4”X14	16	10	57	9.5	55	32
22191-12-12RW	22192-12-12RW	G3/4”X14	20	12	63.2	9.5	65	32
22191-16-12TRW	22192-16-12TRW	G1”X11	20	12	63.2	11	61.5	41
22191-16-16RW	22192-16-16RW	G1”X11	25	16	78.9	11	75	41
22191-20-16TRW	22192-20-16TRW	G1.1/4”X11	25	16	78.9	11	73	50
22191-20-20WRW	22192-20-20RW	G1.1/4”X11	32	20	92.7	10	90	50
22191-24-24WRW	22192-20-21RW	G1.1/2”X11	40	24	111.4	11.5	108	55
22191-32-32WRW	22192-32-32RW	G2”X11	50	32	138.6	15	129.3	70

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	A	C	S1	S2
22611D-04-04RW	--	G1/4”X19	6	04	23	5.5	19	19
22611D-06-06RW	--	G3/8”X19	10	06	25.7	6.3	22	22
22611D-08-08RW	22612D-08-08RW	G1/2”X14	12	08	30.5	7.5	27	27
22611D-10-10RW	22612D-10-10RW	G5/8”X14	10	06	30	9.5	30	30
22611D-12-12RW	22612D-12-12RW	G3/4”X14	20	12	32.1	10.9	32	32
22611D-16-16RW	22612D-16-16RW	G1”X11	25	16	38.5	11.7	41	41
22611D-20-20WRW	22612D-20-20WRW	G1.1/4”X11	32	20	44.7	11	50	50
22611D-24-24WRW	22612D-24-24WRW	G1.1/2”X11	40	24	45	13	55	55
22611D-32-32WRW	22612D-32-32WRW	G2”X11	50	32	51	16	70	70

代号 PART NO.		螺纹E	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	THREADE	公称内径 DN	标号DASH	A	C	S1
12211-02-04RW	--	G1/8”X28	6	04	22	10	12
12211-02-04RW	--	G1/4”X28	6	04	24	12	14
12211-02-04RW	--	G1/4”X28	8	05	24	12	14
12211-02-04RW	--	G1/4”X28	10	06	23.5	12	14
12211-02-04RW	--	G3/8”X19	6	04	25.5	13.5	17
12211-02-04RW	--	G3/8”X19	8	05	25.5	13.5	17
12211-02-04RW	--	G3/8”X19	10	06	25	13.5	17
12211-02-04RW	12212-02-04RW	G3/8”X19	12	08	26	13.5	19
12211-08-06RW	12212-08-06RW	G1/2”X14	10	06	29.5	16	22
12211-08-08RW	12212-08-08RW	G1/2”X14	12	08	30.5	16	22
12211-08-10RW	12212-08-10RW	G1/2”X14	10	06	29.5	16	22
12211-08-12RW	12212-08-12RW	G1/2”X14	20	12	32	16	27
12211-12-08RW	12212-12-08RW	G3/4”X14	12	08	35	18.5	27
12211-12-10RW	12212-12-10RW	G3/4”X14	16	10	35.5	18.5	27
12211-12-12RW	12212-12-12RW	G3/4”X14	20	12	34.5	18.5	27
12211-12-16RW	12212-12-16RW	G3/4”X14	25	16	38.7	18.5	32
12211-16-12RW	12212-16-12RW	G1”X11	20	12	37.5	20.5	36
12211-16-16RW	12212-16-16RW	G1”X11	25	16	40.7	20.5	36
12211-20-20RW	12212-20-20RW	G1.1/4”X11	32	20	42.7	20.5	46
12211-24-24RW	12212-24-24RW	G1.1/2”X11	40	24	48	23	50
12211-32-24RW	12212-32-24RW	G2”X11	40	24	52.5	25.5	65
12211-32-32RW	12212-32-32RW	G2”X11	50	32	56	25.5	65

代号 PART NO.	螺纹E THREAD E	胶管 HOSE BORE		尺寸 DIMENSIONS
代号 PART NO.	螺纹E THREAD E	公称内径 DN	标号 DASH	A	C	S2
22111-02-04	G1/8”X28	6	04	19	2	14
22111-04-03	G1/4”X19	5	03	19	4	19
22111-04-04	G1/4”X19	6	04	19.5	4	19
22111-06-05	G3/8”X19	8	05	20	5	22
22111-06-06	G3/8”X19	10	06	20.5	5	22
22111-06-08	G3/8”X19	12	08	21	5	22
22111-08-06T	G1/2”X14	10	06	22.5	6	27
22111-08-08	G1/2”X14	12	08	23	6	27
22111-08-10	G1/2”X14	16	10	24	6	27
22111-10-10	G5/8”X14	16	10	25	8	30
22111-10-12	G5/8”X14	20	12	25	8	30
22111-12-08T	G3/4”X14	12	08	25	9.5	32
22111-12-10	G3/4”X14	16	10	26	9.5	32
22111-12-12	G3/4”X14	20	12	26	9.5	32
22111-16-12T	G1”X11	20	12	26.5	11	41
22111-16-14	G1”X11	22	14	26.5	11	41
22111-16-16	G1”X11	25	16	28	11	41
22111-20-16T	G1.1/4”X11	25	16	27.5	11	50
22111-20-20W	G1.1/4”X11	32	20	31.5	10	50
22111-24-24W	G1.1/2”X11	40	24	37	11.5	55
22111-32-32W	G2”X11	50	32	34	15	70
注：1.上诉代号用于编制软管。 2.如需用于缠绕软管代码号改为22112-xx-xx。 NOTE : 1.FOR USE WITH BRAIDED HOSES 2.IF USE WITH SPIRAL HOSES ,HOSE FITTINGS SERIES NUMBER IS 22112-XX-XX.

代号	法兰型号	软管		尺寸
代号	法兰型号	公称内径	标号	A	C	D	H	L
87642-08-08	1/2”	12	08	57.5	31.7	24	25	7.75
87642-08-12	1/2”	20	12	77	31.7	24	29.6	7.75
87642-12-10	3/4”	16	10	72.5	41.3	32	28.2	8.76
87642-12-12	3/4”	20	12	75.5	41.3	32	32	8.76
87642-16-16	1”	25	16	86	47.6	38	34	9.53
87642-20-20	1.1/4”	32	20	100	54	44	40	10.29
87642-24-20	1.1/2”	32	20	105.8	63.5	51	45.1	12.57
87642-24-24	1.1/2”	40	24	112	63.5	51	46	12.57
87642-32-24	2”	40	24	125.4	79.4	67	54.7	12.57
87642-32-32	2”	50	32	143	79.4	67	49	12.57
注：1.上诉代号用于编制软管。 2.如需用于缠绕软管代码号改为87642-xx-xx。 NOTE : 1.FOR USE WITH BRAIDED HOSES 2.IF USE WITH SPIRAL HOSES ,HOSE FITTINGS SERIES NUMBER IS 87642-XX-XX.

代号 PART NO.		法兰型号	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	FLANGE SIZE	公称内径 DN	标号DASH	A	C	D	L
87611-08-08RW	87612-08-08RW	1/2”	12	08	48.5	31.7	24	7.75
87611-12-08RW	87612-12-08RW	3/4”	12	08	51.5	41.3	32	8.76
87611-12-10RW	87612-12-10RW	3/4”	16	10	52	41.3	32	8.76
87611-12-12RW	87612-12-12RW	3/4”	20	12	51	41.3	32	8.76
87611-12-16RW	87612-12-16RW	3/4”	25	16	54.2	41.3	32	8.76
87611-16-12RW	87612-16-12RW	1”	20	12	56	47.6	38	9.53
87611-16-16RW	87612-16-16RW	1”	25	16	59.2	47.6	38	9.53
87611-16-20RW	87612-16-20RW	1”	32	20	59.2	47.6	38	9.53
87611-20-16RW	87612-20-16RW	1.1/4”	25	16	67.2	54	44	10.29
87611-20-20RW	87612-20-20RW	1.1/4”	32	20	67.2	54	44	10.29
87611-24-20RW	87612-24-20RW	1.1/2”	32	20	76.2	63.5	51	12.57
87611-24-24RW	87612-24-24RW	1.1/2”	40	24	77	63.5	51	12.57
87611-32-24RW	87612-32-24RW	2”	40	24	88	79.4	67	12.57
87611-32-32RW	87612-32-32RW	2”	50	32	91.5	79.4	67	12.57

代号 PART NO.		法兰型号	胶管 HOSE BORE		尺寸 DIMENSIONS
编织 BRAIDED	缠绕 SPIRAL	FLANGE SIZE	公称内径 DN	标号DASH	A	C	D	L
87311-08-08RW	87311-08-08RW	1/2”	12	08	47.5	30.2	24	6.73
87311-12-08RW	87311-12-08RW	3/4”	12	08	48.5	38.1	31.7	6.73
87311-12-10RW	87311-12-10RW	3/4”	16	10	49	38.1	31.7	6.73
87311-12-12RW	87311-12-12RW	3/4”	20	12	48	38.1	31.7	6.73
87311-12-16RW	87311-12-16RW	3/4”	25	16	51.2	38.1	31.7	6.73
87311-16-12RW	87311-16-12RW	1”	20	12	51	44.4	38	8
87311-16-16RW	87311-16-16RW	1”	25	16	54.2	44.4	38	8
87311-16-20RW	87311-16-20RW	1”	32	20	54.2	44.4	38	8
87311-20-16RW	87311-20-16RW	1.1/4”	25	16	59.2	50.8	43	8
87311-20-20RW	87311-20-20RW	1.1/4”	32	20	59.2	50.8	43	8
87311-24-20RW	87311-24-20RW	1.1/2”	32	20	69.2	60.3	50	8
87311-24-24RW	87311-24-24RW	1.1/2”	40	24	70	60.3	50	8
87311-32-24RW	87311-32-24RW	2”	40	24	72	71.4	62	9.53
87311-32-32RW	87311-32-32RW	2”	50	32	75.5	71.4	62	9.53

代号	法兰型号	软管		尺寸
代号	法兰型号	公称内径	标号	A	C	D	H	L
87692-08-08	1/2”	12	08	42.5	31.7	24	25	7.75
87692-12-10	3/4”	16	10	56	41.3	32	56.5	8.76
87692-12-12	3/4”	20	12	50.5	41.3	32	65.5	8.76
87692-16-12	1”	20	12	65.5	47.6	38	69	9.53
87692-16-16	1”	25	16	66	47.6	38	78	9.53
87692-16-20	1”	32	20	91.5	47.6	38	85.5	9.53
87692-20-16	1.1/4”	25	16	76.7	54	44	78.5	10.29
87692-20-20	1.1/4”	32	20	75	54	44	92	10.29
87692-24-20	1.1/2”	32	20	91.5	63.5	51	94.5	12.57
87692-24-24	1.1/2”	40	24	89	63.5	51	107	12.57
87692-32-24	2”	40	24	109.4	79.4	67	116	12.57
87692-32-32	2”	50	32	115.5	79.4	67	138.5	12.57
注：1.上诉代号用于编制软管。 2.如需用于缠绕软管代码号改为87692-xx-xx。 NOTE : 1.FOR USE WITH BRAIDED HOSES 2.IF USE WITH SPIRAL HOSES ,HOSE FITTINGS SERIES NUMBER IS 87692-XX-XX.

软管内径 I.D.			软管外径 O.D.	工作压力 W.P.		爆破压力 W.P.		最小弯曲半径 MIN.B.P.	参考重量 W.T.
Dash	In.	mm	mm	MPa	psi	MPa	psi	mm	g/m
-4	1/4	6.3	13.5	100	14500	300	43500	110	310
-5	5/16	7.9	15	100	14500	300	43500	130	350
-6	3/8	9.5	18.5	100	14500	300	43500	160	500
-8	1/2	12.7	22	100	14500	300	43500	200	640
